Panasonic PCB Power Relay 12V DC Coil 10A Switching Current SPST ALQ312
Specifications
| Country of Origin | Thailand |
|---|---|
| Brand | Panasonic |
| Height | 15.6mm |
| Length | 20mm |
| Model | ALQ312 |
| Width | 10mm |
| Mount Type | PCB |
| Contact Material | Silver Alloy |
| Series | ALQ |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | SPST |
| Minimum Operating Temperature | -40°C |
| Switching Current | 10A |
| Terminal type | PCB Pin |
| Ambient Temperature | - 40°C to +85°C |
| Contact Resistance | 100mΩ |
| Standards/Approvals | RoHS, VDE |
| Coil Resistance | 720Ω |
| Coil Voltage | 12V dc |
| Switching DC Voltage | 30V dc |
| Switching AC Voltage | 250V |
| Coil Power | 200mW |
| Switching Power | 150W |
| High surge voltage | 8000 V |
| High breakdown voltage | 4000 V |
Key Features
- Compact size ensures efficient PCB mounting in limited spaces.
- High switching power of 150W suitable for demanding electrical loads.
- Wide operating temperature range from -40°C to +85°C ensures durability under harsh conditions.
- Coil resistance of 720 Ohms with low coil power consumption of 200mW.
- High surge voltage resistance of 8000V and breakdown voltage of 4000V for enhanced safety.
- Silver alloy contacts provide low contact resistance of 100 mΩ for efficient conduction.
- Supports both DC switching voltage up to 30V and AC switching voltage up to 250V.
- Ideal for applications such as appliances, robotics, HVAC equipment, and industrial controls.
Product Description
Panasonic ALQ312 PCB Power Relay features a 12V DC coil and a single-pole single-throw (SPST) contact configuration, capable of switching currents up to 10A. It is compact with dimensions of 20mm length, 10mm width, and 15.6mm height, making it well-suited for PCB mounting.
The relay is designed for robustness and reliability, with an operating temperature range extending from -40°C to +85°C. Its coil resistance is 720Ω with a coil power consumption of 200mW, providing efficient power use. It handles switching voltages up to 30V DC and 250V AC, and delivers a switching power capacity of 150W, suitable for a wide range of industrial and commercial applications.
High surge voltage tolerance of 8000 V and breakdown voltage of 4000 V enhance its safety and longevity in high-stress environments. The contact material is silver alloy, ensuring low contact resistance at 100 milliohms, which contributes to reliable electrical conduction. This relay complies with RoHS and VDE standards, reinforcing its environmental compliance and safety credentials.
Common uses include household appliances such as refrigerators, cooking ovens, washing machines, and air conditioners, as well as applications in motor control systems, robotics, and power supply units.
Compact size for efficient PCB integration. Robust performance from -40°C to +85°C operating temperature. High switching capacity of 10A and 150W power rating. Low power coil with 720Ω resistance. High surge and breakdown voltages for operational safety.
Silver alloy contacts for reliable conduction. RoHS and VDE compliant for quality assurance. Discover Panasonic Power Relays and other quality electrical components in the Electronics & Electricals category at EnvMart, crafted for industrial reliability and efficiency.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The relay is capable of switching currents up to 10A.
This model has dimensions of 20mm in length, 10mm in width, and 15.6mm in height.
The coil voltage for this relay is 12V DC.
The relay operates within a temperature range of -40°C to +85°C.
It features a single-pole single-throw (SPST) contact configuration.
The coil power consumption is 200mW.
The contact material is silver alloy, which provides low contact resistance.
The relay has a high surge voltage rating of 8000V and a breakdown voltage of 4000V.
The contact resistance is 100 milliohms (100mΩ).
It complies with RoHS and VDE standards, ensuring environmental compliance and safety.
The maximum switching power capacity is 150W.
It is suitable for applications such as household appliances, robotics, HVAC equipment, and industrial controls.
