Panasonic PCB Power Relay 12V DC Coil 5A Switching Current SPST APAN3112
Specifications
| Country of Origin | China |
|---|---|
| Brand | Panasonic |
| Height | 12.5mm |
| Length | 20mm |
| Model | APAN3112 |
| Width | 5mm |
| Mount Type | PCB |
| Contact Material | Gold Plated |
| Series | Pan |
| Maximum Operating Temperature | 90°C |
| Contact Configuration | SPST |
| Minimum Operating Temperature | -40°C |
| Switching Current | 5A |
| Terminal type | PCB Pin |
| Contact Resistance | 30mΩ |
| Standards/Approvals | RoHS, cULus |
| Coil Resistance | 1.3kΩ |
| Coil Voltage | 12V dc |
| Switching DC Voltage | 110V dc |
| Switching AC Voltage | 110V ac |
| Coil Power | 110mW |
| Switching Power | 150W |
| Low operating power - nominal operating power | 110 mW |
Key Features
- The relay is designed for PCB mounting and offers high density mounting capability.
- It operates at a coil power of 110 mW ensuring low power consumption.
- Contact material is gold plated, providing reliability and low contact resistance of 30 mΩ.
- The operating temperature range spans from -40°C to 90°C for versatile use.
- Switching power is rated at 150W suitable for AC and DC switching at 110V.
- The relay complies with RoHS and cULus standards for safety and environmental requirements.
- Compact dimensions of 20mm length, 12.5mm height, and 5mm width allow easy integration in industrial devices.
- Coil resistance is specified at 1.3 kΩ ensuring stable coil performance.
Product Description
Panasonic APAN3112 PCB Power Relay is a high-quality component designed with a 12V DC coil and SPST (Single Pole Single Throw) contact configuration. It supports a switching current of 5A, making it suitable for various industrial and automation applications. The relay is intended for PCB mounting and offers high density mounting capabilities.
With a nominal coil power of only 110 mW, it ensures energy efficient operation. The contact material is gold plated, resulting in low contact resistance of 30 mΩ and reliable switching performance. This relay operates within a temperature range of -40°C to 90°C, making it appropriate for harsh operating environments.
The switching power rating of 150W at AC/DC voltages of up to 110V allows it to be used in equipment like industrial machines, office devices, measuring instruments, and programmable controllers. The relay is RoHS and cULus compliant, ensuring environmental and safety standards are met.
Its compact construction with dimensions of 20mm length, 12.5mm height, and 5mm width facilitates easy integration into varied circuit boards. The coil resistance is rated at 1.3 kΩ contributing to stable coil operation. This Panasonic relay series emphasizes long insulation distances and complies with IEC61010 reinforced insulation standards.
The relay is optimized for industrial equipment and automation systems requiring reliable PCB-mounted relays. Designed for use in testing devices and temperature controllers where precise switching is needed. Gold plated contacts enhance durability and conductivity.
Compact size enables installation in constrained spaces within electronic devices. Low operating power coil reduces heat generation and energy consumption.
Panasonic presents the APAN3112 as a trusted choice for power relay requirements encompassing industrial manufacturing, control systems, and office automation, combining performance with reliability.
Explore more products in the Power Relays category for comprehensive solutions from renowned brands like Panasonic on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The coil voltage for this relay is 12V DC.
The maximum switching power rating is 150W, suitable for both AC and DC applications.
This model features a Single Pole Single Throw (SPST) contact configuration.
The operating temperature range spans from -40°C to 90°C.
The contact material is gold plated, which provides low contact resistance.
The coil resistance is specified at 1.3 kΩ, ensuring stable coil performance.
The dimensions are 20mm in length, 12.5mm in height, and 5mm in width.
The relay supports a switching current of 5A.
It complies with RoHS and cULus standards for safety and environmental requirements.
This relay is designed for PCB mounting, allowing for high-density integration.
The terminal type is PCB Pin, suitable for direct mounting on printed circuit boards.
The nominal coil power is 110 mW, which ensures low power consumption.
