Cosel DC/DC Converter 3.3V dc 7.5A 76V dc Input 18V Input 24.75W PCB Mount STMGFS30483R3-N1
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | Cosel |
| Efficiency | 89% |
| Length | 117mm |
| Model | STMGFS30483R3-N1 |
| Depth | 27mm |
| Gross Weight | 140g |
| Width | 52mm |
| Mount Type | PCB |
| Series | STMGFS |
| Minimum Operating Temperature | 70°C |
| Number of outputs | 1 |
| Ripple and Noise | 200mV |
| Maximum Output Power | 24.75W |
| Maximum Input Voltage | 76V dc |
| Standards/Approvals | cUL, EN, RoHS, UL, CE, CSA |
| Minimum Input Voltage | 18V |
| Output Voltage 1 | 3.3V dc |
| Output Current 1 | 7.5A |
| Output Voltage Adjustment Range | 2.97 to 3.63 V |
| Isolation Voltage | 500V dc |
Key Features
- Designed for PCB mounting in industrial applications.
- Supports a broad input voltage range from 18V to 76V dc.
- Maximum output power of 24.75 watts with high efficiency of 89%.
- Isolation voltage rated at 500V dc for safety and reliability.
- Built-in protection features including overcurrent and overvoltage protection.
- Output voltage adjustable ±10% within 2.97V to 3.63V range.
- Low ripple and noise at 200mV to ensure stable power delivery.
- Operates reliably between minimum and maximum temperatures of 70°C.
Product Description
Cosel STMGFS30483R3-N1 is a robust DC/DC converter designed for electronic and industrial applications requiring isolated power conversion. This model delivers a regulated 3.3V dc output at 7.5A current, suitable for powering sensitive and precise equipment. The device accommodates wide input voltage ranges from 18V to 76V dc, making it adaptable to various input power sources.
Featuring a PCB mount type, the STMGFS series ensures seamless integration into printed circuit boards with a compact size of 117mm by 52mm by 27mm. Weighing 140 grams, it provides a lightweight solution without compromising durability.
Efficiency is rated at 89%, minimizing energy losses and heat generation. The converter includes built-in protections such as automatic recovery overcurrent protection and overvoltage protection for enhanced reliability. An output voltage adjustment range from 2.97V to 3.63V allows fine-tuning to specific system requirements.
Its 500V dc isolation voltage ensures electrical safety in demanding industrial and commercial environments. Ripple and noise levels are kept low at 200mV to provide stable and clean output power critical for precision electronics.
The converter operates reliably within a temperature range reaching up to 70°C, supporting various industrial conditions. Manufactured in Japan, this product meets international standards including cUL, EN, RoHS, UL, CE, and CSA certifications.
Designed for industrial and commercial DC power conversion applications. Wide 18V to 76V input voltage range with stable output. High efficiency of 89% for energy-saving operation. Built-in protections extend product longevity and safety.
Compact PCB mount package optimizes board space usage. Output voltage adjustable for flexibility in power design. Certified for various international safety and quality standards.
This Cosel STMGFS series DC/DC converter is ideal for industries requiring stable and reliable power supplies including telecommunications, manufacturing, and instrumentation. Explore more DC/DC Converters and electronic power supplies at EnvMart for your specialized applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The input voltage range for this model is from 18V to 76V dc.
This model has a maximum output power of 24.75 watts.
The efficiency of this converter is rated at 89%.
The output voltage can be adjusted within a range of 2.97V to 3.63V.
This model is designed for PCB mounting.
The dimensions are 117mm in length, 52mm in width, and 27mm in depth.
The isolation voltage is rated at 500V dc.
It includes overcurrent and overvoltage protection features for enhanced reliability.
The ripple and noise level is maintained at 200mV.
The maximum operating temperature is 70°C.
This model meets several certifications including cUL, EN, RoHS, UL, CE, and CSA.
The weight of this model is 140 grams.
