Cosel DC/DC Converter, 3.3V DC, 8A Output, 12V DC Input, 26.4W Power, PCB Mount, 6-Pin DIP MGS30123R3-R
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | Cosel |
| Efficiency | 90% |
| Length | 25.4mm |
| Model | MGS30123R3-R |
| Depth | 9.9mm |
| Gross Weight | 40g |
| Width | 9.9mm |
| Mount Type | PCB |
| Series | MGS |
| Maximum Operating Temperature | 85°C |
| Package Type | DIP |
| Minimum Operating Temperature | -40°C |
| Number of outputs | 1 |
| Ripple and Noise | 150mV Pk-Pk |
| Maximum Output Power | 26.4W |
| Maximum Input Voltage | 12V dc |
| Standards/Approvals | UL 60950-1, EN 60950-1, CE, cUL, cULus, TUV |
| Minimum Input Voltage | 9V |
| Number of Pins | 6 |
| Output Voltage 1 | 3.3V dc |
| Output Current 1 | 8A |
| Isolation Voltage | 1.5kV ac |
| High reliability | no built-in aluminium and tantalum electrolytic capacitor |
Key Features
- Industry standard 1" x 1" footprint for compact integration.
- Built-in remote On/Off functionality for controlled operation.
- High efficiency of 90% ensured by synchronized rectification circuit.
- Isolation voltage of 1.5kV AC for enhanced safety and reliability.
- Wide operating temperature range from -40°C to 85°C for versatile use.
- Output voltage adjustable ±10% via external variable resistor.
- Built-in overcurrent protection with automatic recovery.
- No aluminum or tantalum electrolytic capacitors, enhancing reliability.
Product Description
Cosel MGS30123R3-R DC/DC Converter provides a reliable and efficient solution for converting input voltages from 9V to 12V DC to a stable 3.3V DC output at 8A current with a maximum power output of 26.4W. Designed for PCB mounting with a compact 6-pin DIP package measuring 25.4mm by 9.9mm by 9.9mm, it is ideal for tight integration in electronic circuits.
This converter features a high 90% efficiency achieved by its synchronized rectification circuit and includes a built-in remote On/Off function to facilitate control within complex systems. The device exhibits an isolation voltage rating of 1.5kV AC, providing excellent protection against electrical interference and enhancing overall safety. The output voltage is adjustable by ±10% using an external variable resistor allowing fine-tuning for specific requirements.
Its robust construction includes no aluminum or tantalum electrolytic capacitors, improving the operational lifespan and reliability in harsh environments. The unit operates within a temperature range from -40°C to 85°C, catering to diverse industrial and commercial application conditions.
Certified to industry standards including UL 60950-1, EN 60950-1, CE, cUL, cULus, and TUV, this converter assures compliance and quality. The unit weighs 40 grams, making it lightweight and easy to install. Applications include industrial automation, power management systems, telecommunications, instrumentation, and other electronic equipment requiring stable low-voltage DC power from varying input sources.
Industry standard 1" x 1" compact footprint for PCB mounting. Built-in remote On/Off function for operational control. High efficiency of 90% for energy saving and reduced heat. Isolation voltage of 1.5kV AC increases safety and noise immunity.
Wide temperature range -40°C to 85°C for harsh environments. Overcurrent protection with automatic recovery enhances reliability. Output voltage adjustable ±10% using external resistor. Free from aluminum and tantalum electrolytic capacitors.
Meets UL, EN, CE, cUL, cULus, and TUV approval standards. Lightweight at 40g and compact dimensions for easy installation. Explore more high-quality DC/DC Converters by Cosel and find reliable power solutions for your industrial and electronic projects at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum output power of this model is 26.4W.
The output voltage of this unit is 3.3V DC.
It has an efficiency rating of 90% due to its synchronized rectification circuit.
The input voltage range for this converter is between 9V and 12V DC.
The isolation voltage rating is 1.5kV AC, enhancing safety and reliability.
This model operates within a temperature range of -40°C to 85°C.
This converter has one output.
The dimensions of this unit are 25.4mm in length, 9.9mm in width, and 9.9mm in depth.
It is designed for PCB mounting with a 6-pin DIP package.
Yes, it includes built-in overcurrent protection with automatic recovery.
It is certified to UL 60950-1, EN 60950-1, CE, cUL, cULus, and TUV standards.
The weight of this converter is 40 grams.
