TDK-Lambda Encapsulated PCB Mount Switching Power Supply 12V dc, 10.8W, 900mA, Universal Input Voltage KWS10A-12

Free Delivery in India | Lowest Global Shipping Charges

TDK-Lambda Encapsulated PCB Mount Switching Power Supply 12V dc, 10.8W, 900mA, Universal Input Voltage KWS10A-12

Name: TDK-Lambda Encapsulated PCB Mount Switching Power Supply 12V dc, 10.8W, 900mA, Universal Input Voltage KWS10A-12
Brand: TDK-Lambda
SKU: 142091
Price: 73.76 USD
Availability: InStock



Category Switching Power Supplies Brand TDK-Lambda Condition New

Specifications

Country of Origin	Japan
Brand	TDK-Lambda
Power	10.8W
Efficiency	81%
Length	38.1mm
Model	KWS10A-12
Depth	21.5mm
Gross Weight	35g
Width	25.4mm
Mount Type	PCB
Series	KWS10A
Maximum Operating Temperature	85°C
Minimum Operating Temperature	-10°C
Number of outputs	1
Maximum Input Voltage	370, 265V dc
Maximum Output Voltage	12V dc
SMPS Output Current	900mA
Minimum Input Voltage	85V ac

Key Features

Encapsulated PCB mount design suitable for space-critical applications.
Universal input voltage range of 85-265 V ac to 370 V dc.
High efficiency of 81% reducing power losses and improving thermal management.
Compact and lightweight with dimensions 38.1mm x 25.4mm x 21.5mm and weight 35g.
Incorporates overvoltage and overcurrent protection for reliable operation.
Plastic housing complies with UL94V-0 flammability standard.
Conducted noise meets VCCI-II and FCC Class B standards.
Operating temperature range from -10°C to 85°C for versatile industrial use.

Product Description

TDK-Lambda KWS10A-12 is a high-performance encapsulated switching power supply with a PCB mount design. It offers a stable 12V dc output at 10.8 watts and 900mA output current, making it ideal for various industrial and instrumentation applications. The power supply supports a wide universal input voltage range from 85V ac up to 265V ac and a maximum DC input voltage of 370V dc suitable for global use.

This compact unit measures 38.1mm in length, 25.4mm in width, and 21.5mm in depth, weighing only 35 grams, making it fit for space-critical environments. Its efficient design with 81% typical efficiency reduces power losses, thereby facilitating easier thermal management on PCBs. The power supply case is made of plastic compliant with the UL94V-0 flammability rating, ensuring robust protection against fire hazards.

Advanced features include overvoltage and overcurrent protection to safeguard connected electronics. The device complies with several electromagnetic compatibility and safety standards such as CE, FCC Class B, VCCI-B, and IEC/UL/CSA/EN 62368-1, emphasizing its suitability for demanding environments.

It operates reliably across a temperature range of -10°C to 85°C, making it versatile for use in industrial machinery, test and measurement instruments, communication systems, and broadcast equipment. The switching power supply should not be used under sustained short circuit conditions to maintain longevity.

Encapsulated PCB mount switching power supply with compact dimensions. Universal AC input (85-265Vac) and high DC input voltage rating. Efficient 81% typical efficiency reduces heat and energy loss. Protected against overcurrent and overvoltage faults.

Flame-retardant plastic casing rated UL94V-0. Meets CE and international electromagnetic compatibility standards. Designed for industrial, communication, broadcast, and test equipment use. Operating temperature of -10°C to 85°C for robust performance.

Lightweight 35g product suitable for space-limited applications. Certified to IEC/UL/CSA/EN 62368-1 safety standards. Explore more high-quality power supplies and switching power solutions in EnvMart's comprehensive catalog for various industrial and electronic applications.
