XP Power High Voltage DC/DC Converter 1 W 2000V Output PCB Mount CA02P-5

XP Power CA02P-5 DC/DC Converter is a high-performance, high-voltage power supply designed for precise regulation and low noise applications. With a maximum output power of 1 W and a high output voltage of 2000V DC, this PCB mounted converter is suitable for demanding industrial and laboratory applications that require stable and reliable DC voltage conversion.

The converter features a wide input voltage range from 4.75 V to 15.5 V, allowing compatibility with various power sources. It delivers an output current of 5 mA with minimal ripple and noise of just 0.01%, ensuring high signal fidelity for sensitive electronic applications. The shielded case design minimizes EMI and RFI interference and allows the device to withstand immersion cleaning processes, enhancing durability.

Operating reliably within temperature limits of -10 °C to +50 °C, the CA02P-5 includes on-board precision references and calibration adjustment facilities for optimal performance tuning. Its compact dimensions (44.45 mm length, 27.94 mm width, and 12.7 mm depth) and 8-pin configuration make it easy to integrate into printed circuit boards.

Certified conforming to RoHS 2 and 3 Directive (2011/65/EU), CE (RoHS and LVD), and IEC/UL/EN62368 standards, this converter meets international safety and environmental requirements. Typical use cases include powering photomultiplier tubes, avalanche photodiodes, solid-state detectors, electrophoresis equipment, EO lenses, piezo devices, and capacitor charging circuits within industrial, laboratory, and semiconductor manufacturing environments.

Offers a wide input voltage range from 4.75 V to 15.5 V ensuring versatile compatibility. Provides an output current of 5 mA for applications requiring stable current delivery. Equipped with a shielded case for EMI/RFI reduction and immersion cleaning resistance.

Operating temperature range from -10 °C to 50 °C suitable for various environments. Features low ripple and noise of 0.01% ensuring signal integrity. Includes high-level stability with precision on-board reference and calibration adjustment.

Designed with 8 pins in a compact PCB mount form factor measuring 44.45 mm length, 27.94 mm width, and 12.7 mm depth. Built to meet RoHS 2 and 3, CE, and IEC/UL/EN62368 safety and environmental standards. Typical applications include photomultiplier tubes, avalanche photodiodes, electrophoresis, EO lenses, piezo devices, and capacitor charging.

Choose XP Power CA series DC/DC converters for reliable, precision high-voltage conversion suitable for industrial, laboratory, semiconductor, and scientific instrumentation applications. Browse more power supply and converter solutions in the DC/DC Converter category at EnvMart.
