XP Power Isolated DC/DC Converter 9V 333mA 36V/18V Input 6W Through Hole JCD0624D09
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | Converters / DC-DC Converters XP Power JCD DC/DC Converter, 9V/ 333 mA, 36V Inpu |
| Brand | XP Power |
| Efficiency | 83% |
| Length | 31.75mm |
| Model | JCD0624D09 |
| Depth | 10.4mm |
| Width | 20.32mm |
| Mount Type | Through Hole |
| Series | JCD |
| Maximum Operating Temperature | 100°C |
| Package Type | DIP |
| Minimum Operating Temperature | -40°C |
| MTBF | 1100000h |
| Number of outputs | 2 |
| Maximum Output Power | 6W |
| Maximum Input Voltage | 36V |
| Standards/Approvals | RoHS |
| Minimum Input Voltage | 18V |
| Number of Pins | 24 |
| Output Voltage 1 | 9V |
| Output Current 1 | 333mA |
| Output Voltage Adjustment Range | ±9.09 V dc |
| Isolation Voltage | 1.6kV |
| Input Ratio | 2:1 |
| Input Ratio2 | 1 |
Key Features
- It has a maximum operating temperature of 100°C and minimum of -40°C for reliable performance.
- The product offers 1600 VDC isolation ensuring electrical safety in applications.
- Compact DIP package with 24 pins enables easy integration on PCBs.
- Efficiency is rated at 83% for energy-saving operation.
- It is suitable for industrial, laboratory, telecom, and power supply applications.
- Continuous short circuit protection allows for enhanced reliability.
- MTBF is 1,100,000 hours indicating long-term operational dependability.
Product Description
XP Power JCD0624D09 is a highly reliable isolated DC/DC converter designed for applications requiring stable 9V output at 333mA current with an input voltage range from 18V to 36V. This through-hole DIP package device delivers a maximum output power of 6W with an efficiency of 83%, making it ideal for power supply and voltage conversion needs.
The converter supports a 2:1 input ratio allowing usage in flexible input sources and features 1600 VDC isolation between input and output to protect sensitive circuits. It is built to operate reliably over a broad temperature range from -40°C up to 100°C to suit demanding industrial and commercial environments.
Featuring continuous short circuit protection, the device safeguards itself against damage while maintaining performance. With 24 pins in a compact 31.75mm by 20.32mm dimension footprint and 10.4mm depth, it facilitates easy PCB mounting in compact systems.
Typical use cases include industrial automation, telecommunications, laboratory instrumentation, and embedded control systems where isolated, noise-free power supplies are critical. XP Power's JCD series DC/DC converters provide efficient, stable power conversion to enhance system reliability.
The converter has 2 outputs with an output voltage adjustment range of ±9.09 V dc. It complies with RoHS standards assuring environment-friendly manufacturing. The robust design enables a mean time between failures (MTBF) of 1,100,000 hours.
Nominal dimensions: Length 31.75mm, Width 20.32mm, Depth 10.4mm. Country of origin is Taiwan, Province Of China. Explore EnvMart's comprehensive selection of DC/DC Converters for high-quality industrial and commercial power supply solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum output power of this model is 6W.
This unit operates with an input voltage range from 18V to 36V.
It has an efficiency rating of 83%, promoting energy-saving operation.
The dimensions are 31.75mm in length, 20.32mm in width, and 10.4mm in depth.
The isolation voltage is rated at 1600 VDC, ensuring electrical safety in applications.
It operates reliably in temperatures ranging from -40°C to 100°C.
This converter has 2 outputs.
It supports through-hole mounting, suitable for easy integration on PCBs.
The MTBF is rated at 1,100,000 hours, indicating long-term operational dependability.
It complies with RoHS standards, ensuring environment-friendly manufacturing.
The output voltage adjustment range is ±9.09 V dc.
It is suitable for industrial, laboratory, telecom, and power supply applications.
