Nexperia 4-Channel Buffer & Line Driver CMOS Logic IC 3V-15V Supply, 14-Pin SOIC HEF4081BT,652

Free Delivery in India | Lowest Global Shipping Charges

Nexperia 4-Channel Buffer & Line Driver CMOS Logic IC 3V-15V Supply, 14-Pin SOIC HEF4081BT,652

Name: Nexperia 4-Channel Buffer & Line Driver CMOS Logic IC 3V-15V Supply, 14-Pin SOIC HEF4081BT,652
Brand: Nexperia
SKU: 138417
Price: 0.27 USD
Availability: InStock



Category Line Interface ICs Brand Nexperia Condition New

Specifications

Country of Origin	Thailand
Brand	Nexperia
Height	1.75mm
Length	8.75mm
Model	HEF4081BT,652
Width	4mm
Mount Type	Surface
Series	HEF4081B
Input Type	CMOS
Maximum Operating Temperature	124°C
Package Type	SOIC
Minimum Operating Temperature	-40°C
IC Type	Buffer & Line Driver
Number Of Channels	4
Pin Count	14
Maximum Supply Voltage	15V
Logic Family	4000
Logic Function	AND
Minimum Supply Voltage	3V
Maximum High Level Output Current	-4.2mA
Maximum Propagation Delay Time @ CL	20ns
Supply Current	30μA
Maximum Low Level Output Current	4.2mA
Nexperia HEF4081BT,652 Buffer & Line Driver, 14-Pin SOICBrand	Nexperia

Key Features

The quad 2-input AND gates provide fully buffered outputs for enhanced noise immunity.
Supports mixed 5V and 3.3V applications, reducing design complexity.
Features low propagation delay time of 20ns at specified load capacitance.
Operating temperature range spans from -40°C to 124°C for industrial reliability.
CMOS input type with surface mount SOIC package suitable for compact PCB designs.
Low supply current of 30μA enhances power efficiency in embedded applications.
Open-drain output options improve signal integrity in complex layouts.
Wide temperature and voltage operating ranges enable use in diverse electronic environments.

Product Description

Nexperia HEF4081BT,652 is a 4-channel buffer and line driver integrated circuit belonging to the 4000 logic family. This CMOS logic device operates efficiently within a wide supply voltage range of 3 V to 15 V. Packaged in a compact 14-Pin SOIC form factor, it provides quad 2-input AND gate functionality.

The device outputs are fully buffered, ensuring high noise immunity and stable performance even with output impedance variations. The low propagation delay time of 20ns at specified load capacitance aids high-speed signal processing.

Key technical specifications include a supply current of 30μA and a broad operating temperature range from -40°C to 124°C, making it suitable for industrial applications. Its mounting type is surface mount, facilitating easy integration on PCBs.

The HEF4081BT,652 supports mixed voltage applications (5V and 3.3V), allowing designers to save board space and reduce time to market. Open-drain output options contribute to improved signal integrity in complex circuitry.

This line interface IC finds versatile industrial and commercial uses, including in cell phones, computing devices, set-top boxes, LCD televisions, and industrial controllers. The quad 2-input AND gates are buffered for enhanced noise immunity.

Operates across a wide voltage range from 3 V to 15 V. Low supply current consumption of 30μA reduces power usage. Utilizes a 14-pin SOIC surface mount package for compact layout. Industrial-grade temperature operation from -40°C to 124°C ensures reliability.

Improved signal integrity through open-drain output options. Suitable for mixed 3.3V and 5V applications to simplify design. Low propagation delay time supports high-speed digital logic applications. Ideal for use in telecommunications, computing, displays, and industrial control electronics.

This product is a reliable choice for engineers seeking a robust, low-power buffer and line driver IC for integration into sophisticated electronic systems. Explore more semiconductor components and interface ICs in the Nexperia lineup on EnvMart for your project needs.

Explore more products in our Line Interface ICs category.
