KEMET SPST Through Hole Reed Switch 300 mA 110 V AC/DC OHD1-80M

Name: KEMET SPST Through Hole Reed Switch 300 mA 110 V AC/DC OHD1-80M
Brand: KEMET
SKU: 102344
Price: 7.61 USD
Availability: InStock



Category Reed Switch Brand KEMET Condition New

Specifications

Country of Origin	Japan
Brand	KEMET
Length	18mm
Model	OHD1-80M
Depth	5.6mm
Width	5.5mm
Mount Type	Through Hole
Contact Material	Nickel Iron Alloy
Series	OHD Thermal Guard
Maximum Switching Current	300mA
Maximum Operating Temperature	150°C
Contact Configuration	SPST
Minimum Operating Temperature	-20°C
Terminal type	Wire
Contact Resistance	150mΩ
Maximum Switching Power	6W
Standards/Approvals	UL, CSA, TUV, RoHS
Maximum Switching Voltage	110V ac/dc

Key Features

Single pole single throw (SPST) contact configuration provides simple on/off switching.
Maximum switching current of 300 mA suitable for low power circuits.
Switches up to 6 W power for compact circuit integration.
Constructed with nickel iron alloy contact material for durability.
Through hole mount type with wire terminals enables easy PCB assembly.
Wide operating temperature range from -20°C to 150°C for harsh environments.
Compliant with UL, CSA, TUV, and RoHS standards for safety and reliability.
Japan-manufactured with OHD Thermal Guard series design for thermal protection using Thermorite® technology.

Product Description

KEMET OHD1-80M SPST Through Hole Reed Switch is a precision switching component rated for 300 mA maximum current and 110 V AC/DC maximum voltage. It is designed for diverse electrical and automation applications requiring reliable, high-speed on/off operation.

This reed switch features a magnet and the unique Thermorite® soft ferromagnetic material, which changes magnetic properties at elevated temperatures to provide thermal problem countermeasures. This advanced design offers long operational life, excellent environmental durability, and compatibility with signal levels ranging from extremely low (0.1 mW or lower) to high power (6 W).

The switch is constructed with a nickel iron alloy contact material, ensuring consistent contact resistance of 150 mΩ for optimal performance. Its wire terminal type and through hole mounting facilitate easy integration into printed circuit boards.

The product is compact and lightweight, measuring 18 mm in length, 5.5 mm in width, and 5.6 mm in depth. It supports a wide temperature range from -20°C to 150°C, making it suitable for demanding industrial environments. Compliance with UL, CSA, TUV, and RoHS certifications highlights its safety and environmental standards.

Single pole single throw (SPST) contact configuration for simple switching. Maximum switching current of 300 mA and power of 6 W ideal for low-power circuits. Thermorite® thermal guard technology for enhanced thermal protection.

Highly durable nickel iron alloy contacts providing low resistance. Wide temperature range enables use in various industrial and commercial applications. Compliant with key global standards ensuring quality and safety. Compact through hole design for versatile PCB mounting options.

Reliable switching for power transistors, motors, amplifiers, and general appliances.

This KEMET reed switch is widely used in industrial automation, HVAC systems, electronics manufacturing, laboratory instrumentation, and instrumentation requiring compact, reliable switching devices. Its thermal guard capability makes it especially useful for monitoring overheating and power transistor protection.
