Wurth Elektronik WR-PHD Series Right Angle Through Hole Pin Header, 16 Contacts, 2.54 mm Pitch, 2 Row, Unshrouded 61301621021
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | 250V |
| Brand | Wurth Elektronik |
| Orientation | Right Angle |
| Current | 3A |
| Mount Type | Through Hole |
| Housing Material | Polyamide |
| Contact Material | Copper Alloy |
| Series | WR-PHD |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 16 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Tail Pin Length | 3mm |
| Mating Pin Length | 6mm |
Key Features
- Supports 3A current rating for reliable electrical performance.
- Constructed with polyamide housing and copper alloy contacts for durability.
- Gold plated contacts ensure superior conductivity and corrosion resistance.
- Designed with 3 mm solder tail pin length and a 6 mm mating pin length.
- Operating temperature range from -40°C to 105°C enables use in varied environments.
- Right angle orientation optimizes board-to-board connection options.
- Unshrouded design facilitates easy access and soldering.
- Rated for 250V voltage to support typical electronics applications.
Product Description
Wurth Elektronik 61301621021 WR-PHD Series right angle through hole pin header with 16 contacts and 2 row configuration offers precise board-to-board connection solutions for electronics assemblies. The 2.54 mm pitch spacing conforms to industry standards, facilitating integration into existing printed circuit boards.
Featuring a robust polyamide housing, this pin header ensures mechanical stability and thermal resistance with an operating range from -40°C to 105°C. The copper alloy contacts are stamped and gold plated, delivering excellent electrical conductivity and long-lasting corrosion protection.
The product is designed with a 3 mm solder tail pin length and a 6 mm mating pin length, optimizing the soldering process and connector interface. Its right angle orientation supports versatile circuit board layouts while maintaining reliable connections.
This unshrouded pin header accommodates up to 3A current at 250V, making it suitable for various industrial, electronic, and manufacturing applications. It is widely used in power distribution, communication equipment, and control systems where dependable connections are critical.
Manufactured in Taiwan, Province of China, the Wurth Elektronik WR-PHD Series adheres to quality standards and offers durability for demanding environments. Supports 3A current rating for reliable electrical performance.
Constructed with polyamide housing and copper alloy contacts for durability. Gold plated contacts ensure superior conductivity and corrosion resistance. Designed with 3 mm solder tail pin length and a 6 mm mating pin length.
Operating temperature range from -40°C to 105°C enables use in varied environments. Right angle orientation optimizes board-to-board connection options. Unshrouded design facilitates easy access and soldering. Rated for 250V voltage to support typical electronics applications.
Manufactured in Taiwan, Province of China, ensuring quality and compliance.
This right angle through hole pin header is ideal for industrial electronics manufacturing, testing, and prototyping. Explore more Connectors and electronic components in the Electronics & Electricals section to find complementary products for your projects and production lines on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It supports a current rating of 3A, ensuring reliable electrical performance for various applications.
The pin header is rated for 250V, making it suitable for typical electronics applications.
It features a polyamide housing and copper alloy contacts, which contribute to its durability and performance.
The operating temperature range is from -40°C to 105°C, allowing for use in varied environments.
This model has 16 contacts arranged in a 2-row configuration.
The pitch of the contacts is 2.54 mm, conforming to industry standards for easy integration.
The solder tail pin length is 3 mm, designed to optimize the soldering process.
It uses a solder termination type, suitable for through-hole mounting.
This model is unshrouded, which facilitates easy access and soldering.
The orientation is right angle, optimizing board-to-board connection options.
It is manufactured in Taiwan, Province of China, adhering to quality standards.
