Wurth Elektronik WR-PHD Series 2.54mm Pitch Right Angle Through Hole Pin Header, 12 Contacts, 1 Row, Unshrouded 61301211021
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | 250V |
| Brand | Wurth Elektronik |
| Orientation | Right Angle |
| Current | 3A |
| Mount Type | Through Hole |
| Housing Material | Polyamide |
| Contact Material | Copper Alloy |
| Series | WR-PHD |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 12 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Tail Pin Length | 3mm |
| Mating Pin Length | 6mm |
Key Features
- This connector has a single row of unshrouded pins designed for through-hole PCB mounting.
- Contact material is gold-plated copper alloy providing excellent conductivity.
- The housing is made of black polyamide (UL94-V0) ensuring high insulation and flame resistance.
- Rated for 3A current and voltage up to 250V making it suitable for board-to-board applications.
- Operating temperature range spans from -40°C to 105°C ensuring reliability in industrial environments.
- The tail pin length is 3 mm and mating pin length is 6 mm for secure connections.
- Connector orientation is right angle to enable horizontal board stacking.
Product Description
Wurth Elektronik 61301211021 WR-PHD Series right angle through hole pin header connector features a 2.54 mm pitch and 12 male contacts arranged in a single row. This unshrouded connector uses a black polyamide housing rated UL94-V0 for excellent flame retardance.
The contacts are made of copper alloy with gold plating, offering superior electrical conductivity and durability. Rated for 3A current and 250V voltage, this connector is ideal for reliable board-to-board connections in electronic and industrial equipment.
The right angle orientation of the pins facilitates horizontal PCB stacking, saving space in compact designs. It functions efficiently over a temperature range from -40°C to 105°C, making it suitable for harsh industrial, manufacturing, and automation environments.
The connector pins have a tail length of 3 mm for through-hole soldering and a mating pin length of 6 mm to ensure firm engagement with counterpart connectors. This connector is part of the WR-PHD series known for high quality and precision.
Polyamide housing provides mechanical stability and flame resistance. Gold plated copper alloy contacts ensure low resistance and corrosion resistance. Supports current ratings up to 3A and voltage ratings up to 250V. Designed for board-to-board connections with right angle orientation.
Operates reliably in temperatures from -40°C to 105°C. Unshrouded design allows straightforward soldering and inspection.
This pin header connector is manufactured in Taiwan (Province Of China) and is well suited for use in industrial automation, electronics manufacturing, control systems, telecommunications equipment, and other commercial electronic assemblies.
Explore more connectors and electronic components in the EnvMart catalog for your project needs.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for a current of 3A, making it suitable for various board-to-board applications.
It can handle a voltage of up to 250V, ensuring reliable performance in electronic circuits.
The contacts are arranged with a pitch of 2.54mm, which is standard for many PCB applications.
The housing is made of black polyamide (UL94-V0), while the contacts are composed of gold-plated copper alloy for excellent conductivity.
It operates effectively within a temperature range of -40°C to 105°C, suitable for harsh environments.
This connector features 12 male contacts arranged in a single row.
The tail pin length is 3mm, designed for through-hole soldering onto PCBs.
The mating pin length is 6mm, ensuring a secure connection with counterpart connectors.
It utilizes a solder termination type, which is common for through-hole mounting applications.
The pins are oriented at a right angle, allowing for horizontal board stacking.
This pin header connector is manufactured in Taiwan, ensuring adherence to quality standards.
It is well-suited for use in industrial automation, electronics manufacturing, control systems, and telecommunications equipment.
