Schneider Electric Reversing Contactor 110V AC Coil, 3-Pole, 6 A, 2.2 kW Power Rating LC2K0601F7

Schneider Electric LC2K0601F7 reversing contactor is specially designed for simple motor control applications requiring reliable motor reversing capabilities. This compact 3-pole contactor operates with a 110V AC coil at 50/60 Hz frequency and supports motor power ratings of up to 2.2 kW at 400V. Its built-in mechanical interlock and pre-wired reversing circuit ensure safe and efficient motor direction switching.

With a rated contact current of 6 A and contact voltage capacity of up to 600V AC, the contactor is suitable for a range of industrial, manufacturing, HVAC, and automation systems. The device comes with screw clamp terminals enabling solid electrical connections, and its DIN-rail mounting facilitates simple panel installation in control cabinets.

The LC2K0601F7 includes 1 normally closed (NC) auxiliary contact for control and signaling purposes. The product is compliant with widely recognized safety and performance standards such as UL 60947-4-1, CSA C22.2, CE, IEC 60947-4-1, UKCA, EAC, CCC, and CB schemes, making it suitable for global industrial applications. Its operating temperature range from -25°C to 50°C ensures dependable operation in various environments.

This contactor is part of Schneider Electric's TeSys K series and carries the Better World claim for designed disassembly, supporting sustainability efforts. The compact dimensions (90 mm length, 58 mm width, 57 mm depth) make it a space-efficient choice for electrical panels.

Operates with a 110V AC coil voltage suitable for motor control circuits. Features 3 poles and supports contact voltage up to 600V AC. Includes one normally closed (NC) auxiliary contact for signaling and control. Compact DIN-rail mount design with screw clamp terminals for easy installation.

Equipped with a mechanical interlock and pre-wired reversing circuit for motor reversal. Supports motor power ratings up to 2.2 kW (6A AC-3) at 400V supply. Designed and certified according to multiple international standards including UL, CSA, CE, and IEC.

Operating temperature range from -25°C to 50°C for diverse industrial environments. Dimensions optimized for space-saving: 90 mm length, 58 mm width, and 57 mm depth. Constructed for industrial automation, motor control applications, and complies with green sustainable product standards.

This Schneider Electric Reversing Contactor is ideal for industrial automation, motor control, manufacturing equipment, HVAC systems, and other applications requiring reliable and compact motor control solutions. Explore other contactors and auxiliary contacts in the Electronics & Electricals category at EnvMart to complement your industrial control setups.
