WeEn Semiconductors Co., Ltd 4-Pin Surface Mount TRIAC 600 V Gate Trigger 1.5 V BTA2008W-600D,135
Specifications
| Country of Origin | India |
|---|---|
| Brand | WeEn Semiconductors Co., Ltd |
| Height | 1.8mm |
| Length | 6.7mm |
| Model | BTA2008W-600D,135 |
| Mount Type | Surface |
| Configuration | Single |
| Maximum Operating Temperature | 125°C |
| Package Type | SOT-223 |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | RoHS |
| Pin Count | 4 |
| Rated Average On-State Current Irms | 0.8A |
| Repetitive Peak Reverse Voltage VDRM | 600V |
| Surge Current Rating | 9A |
| Maximum Gate Trigger Current Igt | 5mA |
| Maximum Holding Current Ih | 10mA |
| Maximum Gate Trigger Voltage Vgt | 1.5V |
| Peak On-State Voltage | 1.6V |
| Repetitive Peak Off-State Current | 0.5mA |
Key Features
- This TRIAC features a compact SOT-223 package type optimized for surface mounting.
- Gate trigger voltage is rated at a maximum of 1.5 V with a maximum gate trigger current of 5 mA.
- Operating temperature ranges from -40°C to 125°C ensuring reliable performance in diverse environments.
- The device supports surge currents up to 9 A for brief period applications.
- Includes 4 pins with single configuration for versatile AC power control.
- Conforms to RoHS standards and is free from automotive applications certification.
- Compact dimensions include a height of 1.8 mm and length of 6.7 mm for space-sensitive designs.
- Maintains a peak on-state voltage of 1.6 V and repetitive peak off-state current of 0.5 mA.
Product Description
WeEn Semiconductors Co., Ltd BTA2008W-600D,135 is a 4-pin surface mount TRIAC designed for precision AC switching and control applications. With a repetitive peak reverse voltage of 600 V and rated average on-state current of 0.8 A, it is ideal for low to medium power electronics requiring reliable and efficient bidirectional current control.
This device uses a SOT-223 package optimized for surface mounting on printed circuit boards, providing compact and robust mechanical stability. The maximum gate trigger voltage is 1.5 V with a gate trigger current capped at 5 mA, allowing sensitive control of AC load switching.
Operating temperature range from -40°C to 125°C ensures stable performance in industrial, commercial, and residential environments. The TRIAC supports surge current ratings up to 9 A, suitable for managing transient overloads safely.
The device features single configuration with a total of 4 pins, making it appropriate for integration in power control circuits like light dimmers, motor speed controllers, and heater controllers.
Additional features include a peak on-state voltage of 1.6 V and repetitive peak off-state current of 0.5 mA. The component complies with RoHS standards, indicating absence of hazardous substances. While it is not certified for automotive use, it is suitable for a broad range of industrial electronics.
This TRIAC is ideal for industrial automation, lighting control, HVAC systems, and power regulation applications. Its compact surface mount form factor supports high-density PCB designs and efficient thermal management. Robust electrical ratings enable safe switching of AC currents in varied operational settings.
Reliability across wide temperature range allows deployment in harsh and complex environments. Choose WeEn Semiconductors Co., Ltd products at EnvMart for reliable semiconductor components designed to meet stringent industrial standards.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum operating temperature for this model is 125°C, allowing it to perform reliably in various environments.
This TRIAC has a rated average on-state current of 0.8 A, suitable for low to medium power applications.
It comes in a SOT-223 package type, which is optimized for surface mounting on printed circuit boards.
The peak on-state voltage for this TRIAC is 1.6 V, which is important for its operation in AC control applications.
The maximum gate trigger voltage is rated at 1.5 V, with a maximum gate trigger current of 5 mA.
This model supports surge currents up to 9 A for brief periods, making it suitable for managing transient overloads.
The minimum operating temperature for this device is -40°C, allowing it to function in harsh conditions.
It features a total of 4 pins with a single configuration, facilitating its integration into various circuits.
This TRIAC conforms to RoHS standards, indicating it is free from hazardous substances.
It is ideal for applications such as industrial automation, lighting control, HVAC systems, and power regulation.
The dimensions of this model are a height of 1.8 mm and a length of 6.7 mm, making it suitable for space-sensitive designs.
The repetitive peak reverse voltage for this model is 600 V, which is essential for its application in AC control.
