Hirose DF13 Series Right Angle Surface PCB Header, 8 Contacts, 1.25 mm Pitch, 1 Row, Shrouded

Hirose DF13A-8P-1.25H(21) right angle surface PCB header is part of the DF13 series, designed for compact and miniaturized wire-to-board connections in electronic components. This single-row, 8-contact header provides a 1.25 mm pitch and is shrouded to prevent misinsertion, ensuring secure and reliable connectivity in space-constrained PCB layouts.

The header features copper alloy contacts plated with tin for dependable electrical performance and incorporates a friction locking mechanism to maintain a solid connection with its mating housing. Its surface mount termination type allows for robust soldering to the PCB, aided by PCB mounting bosses and metal fittings that prevent solder peeling and provide precise component alignment.

Operating efficiently within a temperature range of -35°C to 85°C and rated for 1A current and 150V voltage, this connector is suitable for numerous industrial and commercial electronic applications including digital cameras, LCD displays, digital video recorders, car navigation systems, access control units, and precision measurement equipment.

The DF13 series is renowned for its compact and space-saving design, with the double row variants offering up to 30% higher density within an identical PCB footprint. This makes the DF13A-8P-1.25H(21) particularly well-suited for portable and handheld devices requiring multiple signal connections.

Manufactured in Japan, this product adheres to high-quality standards ensuring durability and dependability in electronics manufacturing and assembly environments. Its design supports automated pick-and-place mounting and is available with embossed tape and reel packaging, facilitating efficient mass production processes.

Compact, space-saving design suitable for high-density PCB applications. Right angle orientation for optimized PCB layout flexibility. Shrouded housing with polarization slots to prevent incorrect mating. Copper alloy contacts with tin plating ensure reliable electrical performance.

Surface mount type with solder termination for secure mounting. Operating temperature range from -35°C to 85°C supports various environments. Current rating of 1A and voltage rating of 150V for standard electronic applications.

Includes PCB mounting bosses and friction locking for precise placement and secure mating. Manufactured in Japan with premium quality standards. Explore more high-quality PCB Headers and connectors in EnvMart's Electronics Components category.
