Samtec TSW Series Straight Through Hole Pin Header, 18 Contacts, 2.54 mm Pitch, 2 Row, Unshrouded TSW-109-08-L-D
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 550V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 7.6A |
| Model | TSW-109-08-L-D |
| Mount Type | Through Hole |
| Housing Material | Glass Filled Polyester |
| Contact Material | Phosphor Bronze |
| Series | TSW |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 18 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board, Wire-to-Board |
| Tail Pin Length | 5.08mm |
| Mating Pin Length | 5.84mm |
Key Features
- Features a glass filled polyester housing for enhanced durability.
- Utilizes phosphor bronze male contacts plated with gold for superior conductivity.
- Supports a current rating of 7.6A and voltage up to 550V for robust performance.
- Through-hole mount type ensures secure soldered connections on PCBs.
- Operates reliably across a wide temperature range from -55°C to 125°C.
- Tail pin length of 5.08 mm and mating pin length of 5.84 mm for optimal interfacing.
- Compatible with multiple socket strip types designed for board-to-board and wire-to-board connector systems.
- Unshrouded design allows easy mating with corresponding connectors.
Product Description
Samtec TSW-109-08-L-D is a high-quality straight through hole pin header from the TSW Series, designed for robust PCB interconnection applications. Featuring 18 male contacts arranged in 2 rows with a 2.54 mm pitch, this pin header offers reliable and precise electrical connections in both board-to-board and wire-to-board systems.
The connector housing is constructed from durable glass filled polyester, ensuring mechanical stability and resistance under industrial conditions. Contacts are made of phosphor bronze and plated with gold, providing excellent conductivity and corrosion resistance. Rated for a current of 7.6A and voltage of up to 550V, the TSW-109-08-L-D pin header meets demanding operational requirements.
This through hole mount component facilitates secure soldered connections on printed circuit boards and operates efficiently within a temperature range from -55°C to 125°C, making it suitable for a broad spectrum of industrial, manufacturing, and electronics assembly use cases. The unshrouded design enables easy interfacing with compatible socket strips.
Additional product details include a tail pin length of 5.08 mm and mating pin length of 5.84 mm, contributing to reliable and durable connector engagement. This model offers excellent flexibility with multiple configuration options in the TSW series, satisfying various design and assembly needs.
Durable glass filled polyester housing enhances ruggedness. Gold plated phosphor bronze contacts ensure superior conductivity. Supports 7.6A current and 550V voltage ratings for dependable performance. Wide temperature range from -55°C to 125°C for versatile applications.
Through hole mount provides secure PCB attachment. Unshrouded 2-row, 18-contact configuration with 2.54 mm pitch. Tail pin length of 5.08 mm and mating pin length of 5.84 mm. Compatible with various socket strip types for board-to-board and wire-to-board connections.
This Samtec TSW Series pin header is ideal for use in industrial electronics, manufacturing, telecommunications, and other sectors requiring reliable and precise PCB connector solutions. For further product exploration, browse related categories and Samtec connectors on EnvMart.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The TSW-109-08-L-D pin header supports a current rating of 7.6A.
It can handle voltages up to 550V.
The contacts are arranged with a pitch of 2.54 mm.
The tail pin length is 5.08 mm and the mating pin length is 5.84 mm.
The housing is made of glass filled polyester, and the contacts are phosphor bronze plated with gold.
It operates reliably across a temperature range from -55°C to 125°C.
This pin header features 18 male contacts arranged in 2 rows.
It uses a through hole mount type for secure soldered connections on PCBs.
Yes, it is compatible with multiple socket strip types designed for board-to-board and wire-to-board systems.
The TSW-109-08-L-D pin header has a straight orientation.
It utilizes solder termination for secure connections.
This model is part of the TSW series of pin headers.
