Samtec TSM Series Straight Surface Pin Header 14 Contacts 2.54 mm Pitch 2 Row Unshrouded TSM-107-01-L-DV
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 475V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 7A |
| Model | TSM-107-01-L-DV |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | TSM |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 14 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board, Wire-to-Board |
| Mating Pin Length | 5.84mm |
Key Features
- The pin header utilizes a black liquid crystal polymer housing for enhanced durability.
- Contacts are made of phosphor bronze with 0.25μm gold plating on posts to ensure reliable electrical performance.
- Designed with a 5.84 mm mating pin length for optimal connection stability.
- Operates effectively within a wide temperature range from -55°C to 125°C.
- Supports a current rating of 7A and a voltage rating of 475V for robust power handling.
- Surface mount technology (SMT) design facilitates easy PCB assembly.
- The unshrouded design allows flexible mating options and easy access for connectors.
- Applicable in industrial, electronics manufacturing, and power distribution systems.
Product Description
Samtec TSM-107-01-L-DV is a high-quality straight surface mount pin header from the TSM Series. It features 14 male contacts arranged in 2 rows with a standard 2.54 mm pitch, designed specifically for board-to-board and wire-to-board connections.
The header includes a black liquid crystal polymer housing, providing excellent mechanical strength and thermal stability. Phosphor bronze contacts with gold plating on the mating posts ensure superior conductivity and corrosion resistance, essential for reliable electronic performance.
The mating pin length of 5.84 mm provides secure and stable electrical mating. The header is capable of handling up to 7A current and 475V voltage, making it suitable for demanding electrical applications. This connector operates reliably in temperatures ranging from -55°C to 125°C, ensuring robustness in diverse industrial and commercial environments.
The surface mount termination type simplifies PCB assembly processes and enables integration into compact electronic designs. Its unshrouded configuration allows for flexible connector mating and easy inspection of connections.
Typical applications include electronic manufacturing, power distribution, telecommunications, instrumentation, and other industrial systems requiring reliable interconnects with high current and voltage tolerance.
The pin header features a durable liquid crystal polymer housing. Phosphor bronze contacts with gold plating ensure reliable signal and power transmission. Wide temperature operating range from -55°C to 125°C accommodates harsh environments.
14 contacts arranged in 2 rows at 2.54 mm pitch meet industry-standard spacing. Suitable for surface mount technology (SMT) PCB assembly. Supports board-to-board and wire-to-board connector systems. Unshrouded design offers flexible mating options and easy access.
Ensures stable connections with a 5.84 mm mating pin length. Explore more high-quality PCB Headers and connectors on EnvMart for your electronic component needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The voltage rating of this pin header is 475V, making it suitable for robust power handling applications.
This model supports a current rating of 7A, allowing it to handle significant electrical loads.
It operates effectively within a temperature range of -55°C to 125°C, accommodating various environmental conditions.
This pin header features 14 male contacts arranged in 2 rows, providing multiple connection points.
The contacts are arranged with a standard pitch of 2.54 mm, which is widely used in electronic applications.
The housing is made of liquid crystal polymer, while the contacts are made of phosphor bronze with gold plating for enhanced conductivity.
This model uses a solder termination type, suitable for surface mount technology (SMT) assembly.
The mating pin length is 5.84 mm, ensuring stable and secure electrical connections.
Yes, it is designed for surface mount technology (SMT), facilitating easy PCB assembly.
It supports both board-to-board and wire-to-board connector systems, providing versatility in applications.
The orientation of this pin header is straight, allowing for straightforward connections in electronic designs.
The pin header is manufactured in India, ensuring compliance with specific regional manufacturing standards.
