JST ZH Series Female Crimp Terminal 1A Current 28 AWG min, 26 AWG max MINI-SZH-002T-P0.5

Free Delivery in India | Lowest Global Shipping Charges

JST ZH Series Female Crimp Terminal 1A Current 28 AWG min, 26 AWG max MINI-SZH-002T-P0.5



Category Crimp Contacts Brand JST Condition New

Specifications

Country of Origin	United Kingdom
Brand	JST
Current	1A
Model	MINI-SZH-002T-P0.5
Gender	Female
Contact Material	Phosphor Bronze
Series	ZH
Termination Type	Crimp
Maximum Operating Temperature	85°C
Minimum Operating Temperature	-25°C
Interfaces	lances
For Use With	ZH Series Connectors
Contact Plating	Tin
Minimum Wire Size mm²	0.08mm²
Maximum Wire Size mm²	0.1mm²
Minimum Wire Size AWG	28AWG
Maximum Wire Size AWG	26AWG
Maximum Contact Resistance	20mΩ

Key Features

Compact design with a mounting height of 5.6 mm and thickness of 3.5 mm.
Constructed from phosphor bronze with tin plating for reliable contact.
Suitable for crimp termination ensuring durable electrical connections.
Supports a wide operating temperature range from -25°C to 85°C.
Contact resistance maximum of 20 milliohms.
Features contact retention lances for secure housing insertion.
Compatible with ZR insulation displacement connectors.
Ideal for use in electronics, industrial automation, and PCB assemblies.

Product Description

The JST ZH Series Female Crimp Terminal MINI-SZH-002T-P0.5 is engineered for precise and reliable electrical connections in compact PCB designs. Designed specifically for ZH series connectors, it supports wire sizes of 28 AWG minimum and 26 AWG maximum, with a current rating of 1 ampere.

This terminal is formed from high-quality phosphor bronze and features a tin plating to ensure excellent conductivity and corrosion resistance. Its compact form factor includes a mounting height of 5.6 mm and a slim thickness of 3.5 mm, making it ideal for space-constrained electronic applications.

The crimp termination style provides secure wire attachment, supported by contact retention lances in the housing to facilitate easy insertion and reliable engagement. A dimple at the center of the contact ensures consistent contact with connector posts.

Designed to operate reliably across a temperature range of -25°C to 85°C, this crimp terminal features a maximum contact resistance of 20 milliohms, supporting efficient electrical performance.

The JST ZH Series terminal is compatible with ZR insulation displacement connectors, extending its versatility in various industrial and electronic applications including manufacturing, automation systems, and laboratory instrumentation.

Manufactured in the United Kingdom, the product adheres to rigorous quality standards, suitable for clients requiring dependable PCB connector solutions. Compact, low profile 5.6 mm mounting height design. Phosphor bronze construction with tin plating for durability.

Reliable contact retention enabled by housing lances. Supports wire sizes from 28 AWG to 26 AWG with 1A current rating. Wide operating temperature range from -25°C to 85°C. Maximum contact resistance of 20 milliohms ensures minimal power loss.

Compatible with ZR insulation displacement connectors. Ideal for industrial automation, electronics, and PCB assemblies. Manufactured in the United Kingdom for assured quality.

Choose JST ZH Series Female Crimp Terminals for compact, reliable, and high-quality crimp terminal solutions. Browse our extensive selection of connectors and electronic components at EnvMart.

Explore more products in our Crimp Contacts category.
