Amphenol Communications Solutions 24-Way 2 Row IDC Male Connector for Cable, 230V, 1A TMM-1-0-24-1

Amphenol Communications Solutions TMM-1-0-24-1 is a high-quality 24-way IDC (Insulation Displacement Connector) male connector designed for cable mounting. With 2 rows of tin-plated copper contacts and a durable thermoplastic housing, this connector delivers excellent electrical and mechanical performance for electronic assemblies and wire to board connections. Rated at 230V and 1A current, it features a right angle orientation suitable for compact PCB layouts and reduces cable strain.

The TMM series connectors utilize a 1.27 mm pitch spacing, making them compatible with ribbon cables typically used in telecommunications, computing, and industrial electronics. The male connector mates securely with corresponding TMM MicroMatch female headers that incorporate locking latches and polarization guides, ensuring proper mating and preventing misalignment during installation.

Manufactured with a design focus on reliability, the fully tinned contacts resist corrosion and facilitate soldering with kinked PCB tails for improved retention. The thermoplastic housing material provides insulation and resistance to mechanical stress, while the contact plating of tin maintains efficient conductivity. Operating temperature ranges from -40°C to 105°C permit use in a wide spectrum of industrial, laboratory, and commercial applications.

This connector from Amphenol is ideal for cable harnessing, electronic instrumentation, industrial control systems, telecommunications equipment, and any application requiring a compact, reliable wire-to-board connection. The product is made in China and supplied as new, meeting exacting quality standards for electronic components.

Features 24 copper contacts arranged in 2 rows for efficient wire to board connection. Supports 1.27 mm pitch ribbon cable with tin-plated contacts ensuring reliable solder termination. Connector is male type with thermoplastic housing providing durability and insulation.

Operates reliably in temperatures ranging from -40°C to 105°C, suitable for demanding environments. Designed for use with TMM MicroMatch female headers ensuring secure locking and correct polarization. The contacts’ PCB tails are kinked to improve header retention during soldering operations.

The connector's compact 2.54mm pitch follows standard IDC Connector formats for compatibility. Ideal for electronic applications requiring robust, compact, right angle connectors. Explore more electronic connectors and components at EnvMart to find compatible parts for your industrial, manufacturing, laboratory, or commercial electronic assembly needs.
