Amphenol Communications Solutions 16-Way IDC Connector Male for Cable, 2 Row TMM-2-0-16-1
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 230V |
| Brand | Amphenol Communications Solutions |
| Orientation | Right Angle |
| Current | 1A |
| Model | TMM-2-0-16-1 |
| Mount Type | Cable |
| Housing Material | Thermoplastic |
| Contact Material | Beryllium Copper |
| Series | TMM |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Tin |
| Number of Contacts | 16 |
| Contact Gender | Male |
| Connector Gender | Male |
| Shrouded/Unshrouded | Shrouded |
Key Features
- Provides a shrouded male IDC connector designed for wire-to-board connections.
- Features a 2.54 mm pitch suitable for 1.27 mm pitch ribbon wire 28AWG.
- Rated for 1A current and 230V operation with a maximum temperature of 105°C.
- Right angle orientation with tin-plated beryllium copper contacts for durability.
- Housing constructed from thermoplastic material ensuring insulation and robustness.
- Suitable for industrial, electronic component assemblies and wiring applications.
- Offers reliable contact retention with solder termination and polarization guides.
Product Description
Amphenol Communications Solutions TMM-2-0-16-1 is a 16-way male IDC connector designed for cable-to-board connections, featuring two rows and a 2.54 mm pitch. This shrouded IDC paddle board connector supports ribbon cable connections with 1.27 mm pitch 28AWG wire, ensuring stable and efficient electrical contact for electronic assemblies.
This connector is rated for 1A current and operates safely at voltages up to 230V. It can withstand environmental conditions within a range from -40°C to 105°C, making it suitable for diverse industrial applications including electronics manufacturing, HVAC control systems, laboratory equipment wiring, and power distribution assemblies.
Constructed using thermoplastic housing and beryllium copper contacts plated with tin, the connector ensures durable mechanical and electrical performance. The male connector's polarization guide enhances correct orientation during installation, and the right angle design facilitates compact assembly in constrained spaces.
Solder termination type allows secure mounting on ribbon cables or PCB headers, optimizing retention with kinked tails for better solder joints. These connectors are widely used in manufacturing environments that demand reliable wire-to-board interconnections, electronic component housings, and power connector assemblies.
Shrouded male IDC connector engineered for precise wire-to-board mating. Robust thermoplastic housing paired with tin-plated beryllium copper contacts for reliable conductivity. Designed for 1.27 mm pitch ribbon cables using 28AWG wire standard.
Operates safely at 230V and 1A current with a temperature range from -40°C to 105°C. Right angle orientation aids in compact and efficient PCB layout. Polarization feature ensures correct connector alignment, reducing assembly errors.
Termination by solder enables strong cable retention and mechanical stability. Suitable for industrial, electronic component, laboratory, HVAC, and manufacturing applications. Explore EnvMart's extensive catalog for more industrial-grade IDC Connectors and electronic component solutions for reliable and precise wiring configurations.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This IDC connector is rated for a maximum voltage of 230V.
The current rating for this model is 1A.
It can operate safely within a temperature range of -40°C to 105°C.
This model uses solder termination for secure mounting.
The pitch size of the contacts is 2.54 mm.
The connector features 16 contacts.
The housing is made from thermoplastic, and the contacts are made from beryllium copper with tin plating.
This connector has a right angle orientation.
Yes, it is suitable for industrial applications, including electronics manufacturing and power distribution assemblies.
It is designed for use with 1.27 mm pitch ribbon cables using 28AWG wire.
Yes, it includes a polarization guide to ensure correct orientation during installation.
The connector is manufactured in China.
