Crydom EZ Series Solid State Relay 18 A Load Panel Mount 280 Vrms Load 32V dc Control EZE240D18
Specifications
| Country of Origin | Mexico |
|---|---|
| Brand | Crydom |
| Height | 24.1mm |
| Length | 66.8mm |
| Model | EZE240D18 |
| Width | 24.1mm |
| Mount Type | Panel |
| Output type | SCR |
| Series | EZ |
| Maximum Operating Temperature | 80°C |
| Contact Configuration | SPST |
| Capacitance | 8pF |
| Minimum Operating Temperature | -40°C |
| Terminal type | Quick Connect |
| Switching Function | Zero Cross Switching |
| Maximum Load Current | 18A |
| Standards/Approvals | CE, CSA, RoHS, UL, VDE |
| Minimum Control Voltage | 15V dc |
| Maximum Control Voltage | 32V dc |
| Off State Leakage Current | 0.1mArms |
Key Features
- Compact panel mount design suitable for low-profile applications.
- Supports maximum load current of 18 A and load voltage up to 280 Vrms.
- Control voltage ranges from 15V DC minimum to 32V DC maximum.
- Features quick connect terminal types for easy installation.
- Utilizes zero cross switching to minimize electrical noise.
- Capable of operating in temperatures from -40°C to 80°C with reliable performance.
- Off state leakage current is minimal at 0.1 mArms for efficiency.
- SCR output type designed for heavy industrial AC loads.
Product Description
Crydom EZE240D18 is a high-performance solid state relay designed for industrial, automation, and electrical control applications. It features an 18 A maximum load current capacity with a load voltage rating of 280 Vrms, making it ideal for controlling heavy AC loads with high efficiency and low noise.
The relay is designed for panel mounting with compact dimensions of 66.8mm length, 24.1mm width, and 24.1mm height, suitable for low-profile installation where space is limited. It uses quick connect terminals enabling fast and secure wiring.
Engineered with zero cross switching functionality, the relay reduces electrical noise and prolongs the life of both the relay and connected devices. It operates reliably within a wide temperature range from -40°C to 80°C, accommodating demanding industrial environments.
Off state leakage current is very low at 0.1 mArms, enhancing energy efficiency during operation. The SCR output type is optimized for controlling AC loads and heavy-duty industrial control systems.
Compact panel mount design for space optimization. 18 A maximum load current supporting robust equipment. Zero cross switching to reduce electrical interference. Quick connect terminals for easy and secure connections. Wide operating temperature range from -40°C to 80°C.
Low off state leakage current ensures energy efficiency. Certified to CE, CSA, RoHS, UL, and VDE standards. Manufactured in Mexico ensuring consistent quality.
This solid state relay series is highly suitable for industrial automation, manufacturing equipment control, HVAC systems, and electrical panels requiring reliable and efficient switching of AC loads. The compact size and robust certifications allow it to meet rigorous industrial standards.
Explore the comprehensive range of Crydom Solid State Relays and related products in the EnvMart Electronics & Electricals section for advanced relay solutions tailored to your industrial automation needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum load current for this model is 18 A.
This solid state relay has a load voltage rating of up to 280 Vrms.
It supports a control voltage range from 15V DC minimum to 32V DC maximum.
It utilizes zero cross switching to minimize electrical noise.
The dimensions are 66.8 mm in length, 24.1 mm in width, and 24.1 mm in height.
It operates reliably in temperatures ranging from -40°C to 80°C.
It features quick connect terminals for easy installation.
This model is certified to CE, CSA, RoHS, UL, and VDE standards.
The off state leakage current is minimal at 0.1 mArms.
The output type is SCR, designed for controlling heavy industrial AC loads.
It is suitable for industrial automation, manufacturing equipment control, HVAC systems, and electrical panels.
This solid state relay is manufactured in Mexico.
