Preci-Dip 811 Series Straight Surface Spring Loaded Connector, 3 Contacts, 2.54 mm Pitch, 1 Row 811-S1-003-30-016191
Specifications
| Country of Origin | Switzerland |
|---|---|
| Voltage | 150V |
| Brand | Preci-Dip |
| Orientation | Straight |
| Current | 3.5A |
| Model | 811-S1-003-30-016191 |
| Mount Type | Surface |
| Housing Material | Fibreglass Reinforced Polyethylene Terephthalate |
| Contact Material | Brass |
| Series | 811 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 3 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
Key Features
- The connector has a single row configuration with 3 contacts for reliable connectivity.
- Shrouded housing provides protection and ensures secure mating.
- Contacts are made of brass with gold plating for low resistance and durability.
- Housing material is Fibreglass Reinforced Polyethylene Terephthalate for strength and thermal resistance.
- Operates reliably between -55°C and 125°C temperature range.
- Rated for a current of 3.5 A and voltage of 150 V.
- Designed for surface mount with solder termination and male contact gender.
- Suitable for industrial, electronic manufacturing, and PCB assembly applications.
Product Description
Preci-Dip 811-S1-003-30-016191 is a straight surface spring loaded connector designed for advanced PCB connectivity needs. It features 3 contacts in a single row with 2.54 mm pitch, making it suitable for precise electronic component connections.
The connector's shrouded design enhances protection, and its housing is made from Fibreglass Reinforced Polyethylene Terephthalate, providing excellent mechanical strength and heat resistance. The contacts utilize brass material with gold plating, ensuring durable, low resistance electrical performance.
Operating over a broad temperature range from -55°C to 125°C, the connector supports currents up to 3.5 A and voltages up to 150 V. Its surface mount termination type simplifies PCB assembly with reliable solder connections, and the male contact gender meets common industry standards.
This Preci-Dip spring loaded connector provides consistent, low micro-discontinuity multipoint electrical connections suitable for industrial, electronic manufacturing, laboratory, and communications equipment applications. Its spring loaded contact technology ensures the electrical connection maintains reliability even under vibration or movement conditions.
Manufactured in Switzerland, this component supports high quality demands, catering to specialized electronics assembly environments. It is an excellent choice for engineers and technicians seeking dependable PCB connector solutions with precise pitch and durable design.
The connector has a single row configuration with 3 contacts for reliable connectivity. Shrouded housing provides protection and ensures secure mating. Contacts are made of brass with gold plating for low resistance and durability.
Housing material is Fibreglass Reinforced Polyethylene Terephthalate for strength and thermal resistance. Operates reliably between -55°C and 125°C temperature range. Rated for a current of 3.5 A and voltage of 150 V. Designed for surface mount with solder termination and male contact gender.
Suitable for industrial, electronic manufacturing, and PCB assembly applications. Ensures stable, low electrical resistance with spring-loaded contact technology. Manufactured in Switzerland, assuring high quality standards.
Explore more electronics components and connectors at EnvMart for your projects and manufacturing needs.
Explore more products in our PCB Connectors & Wire Housings category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The connector is rated for a maximum current of 3.5 A.
It can handle a maximum voltage of 150 V.
The contacts are arranged with a pitch of 2.54 mm.
It operates reliably between -55°C and 125°C.
The contacts are made of brass with gold plating, while the housing is constructed from Fibreglass Reinforced Polyethylene Terephthalate.
This model features 3 contacts in a single row configuration.
It uses a solder termination type for surface mounting.
The connector has a shrouded design, providing enhanced protection during mating.
This connector features male contact gender.
The connector is manufactured in Switzerland.
It is suitable for industrial, electronic manufacturing, and PCB assembly applications.
The orientation of this connector is straight.
