HARTING 64-Way IDC Connector Male for Cable, 2 Row, 320V AC, 1A Current, Right Angle, SEK 18 Series 09181649622
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 320V ac |
| Brand | HARTING |
| Orientation | Right Angle |
| Current | 1A |
| Mount Type | Cable |
| Housing Material | Polybutylene Terephthalate |
| Contact Material | Copper Alloy |
| Series | SEK 18 |
| Termination Type | IDC |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Tin |
| Number of Contacts | 64 |
| Contact Gender | Male |
| Connector Gender | Male |
| Shrouded/Unshrouded | Shrouded |
Key Features
- Features 64 contacts arranged in 2 rows for high-density applications.
- Supports a current rating of 1 ampere ensuring efficient power transmission.
- Has a pitch of 2.54 mm suitable for standard IDC flat cables.
- Connector housing is made of durable polybutylene terephthalate material.
- Operates safely between -55°C and 105°C temperature range.
- Right angle orientation enhances cable routing flexibility.
- Tin-plated copper alloy contacts provide good conductivity and corrosion resistance.
- Compatible with IDC flat cable 1.27 mm pitch AWG 28/7 for easy termination.
Product Description
HARTING 09181649622 IDC Connector Male for Cable, featuring 64 ways in 2 rows, is engineered for industrial and electronic applications where reliable PCB transition connectors are required. Rated for 320V AC and 1A current, this connector ensures stable electrical connections in compact spaces.
The low-profile design with 5.5 mm height allows easy integration in tight assemblies. It supports right angle orientation and cable mounting, making it ideal for intricate wiring harness designs.
The housing material is high-quality polybutylene terephthalate, which provides excellent mechanical strength and chemical resistance. Copper alloy contacts with tin plating assure good electrical conductivity and corrosion protection.
Operating within a temperature range from -55°C to 105°C, the HARTING IDC connector is suitable for demanding environments. The connector series is SEK 18 and termination style is IDC, suitable for flat cables with 1.27 mm pitch, AWG 28/7, enabling quick and reliable installation.
64 contacts arranged in 2 rows for high-density applications. Current rating of 1 ampere for efficient power transmission. Pitch of 2.54 mm fits standard IDC flat cables. Polybutylene terephthalate housing for durability.
Operational temperature from -55°C to 105°C. Right angle cable mounting for optimized cable routing. Tin plated copper alloy contacts for excellent conductivity. Low-profile design measuring 5.5 mm in height. Compatible with IDC flat cable 1.27 mm pitch AWG 28/7.
This IDC Connector is widely used in electronics manufacturing, industrial controls, telecommunications, and computer hardware applications. Its robust design supports long-term reliability in harsh environments.
Explore more high-quality HARTING connectors and electronic components to enhance your industrial assembly and automation projects at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The connector is rated for 320V AC, ensuring stable electrical connections in various applications.
It has a current rating of 1 ampere, which supports efficient power transmission.
The pitch is 2.54 mm, making it suitable for standard IDC flat cables.
It is compatible with IDC flat cable that has a 1.27 mm pitch and AWG 28/7 for easy termination.
This model operates safely between -55°C and 105°C, making it suitable for demanding environments.
The housing is made of polybutylene terephthalate, which provides excellent mechanical strength and chemical resistance.
It features 64 contacts arranged in 2 rows, designed for high-density applications.
This connector has a right angle orientation, which enhances cable routing flexibility.
It uses IDC (Insulation Displacement Connector) termination style, suitable for quick and reliable installation.
The contacts are made of tin-plated copper alloy, which provides good conductivity and corrosion resistance.
The low-profile design measures 5.5 mm in height, allowing for easy integration in tight assemblies.
This connector is part of the SEK 18 series, designed for industrial and electronic applications.
