Semtech 1-Element Uni-Directional TVS Diode Array 50W 6-Pin SOT-505 RCLAMP0502A.TCT

Free Delivery in India | Lowest Global Shipping Charges

Semtech 1-Element Uni-Directional TVS Diode Array 50W 6-Pin SOT-505 RCLAMP0502A.TCT

Name: Semtech 1-Element Uni-Directional TVS Diode Array 50W 6-Pin SOT-505 RCLAMP0502A.TCT
Brand: Semtech
SKU: 126745
Price: 0.69 USD
Availability: InStock



Category TVS Diode Array Brand Semtech Condition New

Specifications

Country of Origin	India
Brand	Semtech
Height	0.6mm
Length	1.6mm
Model	RCLAMP0502A.TCT
Width	1.2mm
Mount Type	Surface
Series	RCLAMP0502A
Maximum Operating Temperature	125°C
Package Type	SOT-505
Minimum Operating Temperature	-55°C
Pin Count	6
Number of Elements per Chip	1
Clamping Voltage VC	18V
Diode Configuration	Single
Direction Type	Uni-Directional
Minimum Breakdown Voltage Vbr	6V
Maximum Reverse Stand-off Voltage Vwm	5V
Peak Pulse Power Dissipation Pppm	50W
Test Current It	1mA
Maximum Peak Pulse Current Ippm	3A
Maximum Reverse Leakage Current	1μA

Key Features

This TVS diode array provides effective transient voltage suppression in electronic circuits.
Uni-directional diode configuration offers reliable protection against voltage spikes.
Peak pulse power dissipation rating of 50 watts ensures robust surge handling capability.
Compact surface-mount SOT-505 package with 6 pins supports easy PCB integration.
Operating temperature range from -55°C to 125°C fits diverse industrial and electronic applications.
Clamping voltage of 18 volts and minimum breakdown voltage of 6 volts ensure prompt transient voltage suppression.
Maximum peak pulse current of 3 amperes enhances circuit protection during transient events.
Low maximum reverse leakage current of 1μA minimizes power loss when inactive.

Product Description

Semtech RCLAMP0502A.TCT is a 1-element uni-directional transient voltage suppression (TVS) diode array designed for high-current lightning and surge protection in electronics. It features a peak pulse power dissipation capability of 50 watts and comes in a compact 6-pin SOT-505 surface mount package. Ideal for industrial, telecommunications, computing, and consumer electronics applications.

This TVS diode array protects sensitive electronic circuits from transient voltage spikes caused by lightning strikes or switching transients. Its uni-directional diode configuration ensures optimal protection polarity and rapid response time.

The device operates reliably over a wide temperature range from -55°C to 125°C, supporting harsh environmental conditions. With a minimum breakdown voltage of 6 volts and a clamping voltage of 18 volts, it effectively limits voltage transients to safe levels.

It supports a maximum peak pulse current of 3 amperes while maintaining a low reverse leakage current of 1μA, which reduces leakage power dissipation in normal operation. The device’s compact dimensions (1.6mm length, 1.2mm width, 0.6mm height) optimize PCB space usage.

This diode array is surface mount solderable and suitable for automated assembly processes. ESD protection ensures durable device performance and longevity. Package and pin configuration enable easy integration into existing circuit designs.

Widely used in electronic components requiring lightning and surge transient protection. This model RCLAMP0502A.TCT is part of the RCLAMP0502A series and complies with applicable industry standards except specific approvals are not listed.

For buyers looking for high-reliability TVS diode arrays with compact form factor and strong surge handling, the Semtech RCLAMP0502A.TCT is a suitable choice across multiple electronics manufacturing and repair scenarios.
