TE Connectivity IDC Connector 14 Contacts 2 Row Shrouded Female Right Angle AMP-LATCH 1A 1000V 1-215911-4
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 1000V |
| Brand | TE Connectivity |
| Orientation | Right Angle |
| Current | 1A |
| Mount Type | Cable |
| Housing Material | Polyethylene Terephthalate |
| Contact Material | Phosphor Bronze |
| Series | AMP-LATCH |
| Termination Type | IDC |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold over Nickel |
| Number of Contacts | 14 |
| Contact Gender | Female |
| Connector Gender | Female |
| Shrouded/Unshrouded | Shrouded |
Key Features
- The connector supports a current rating of 1 Ampere and voltage up to 1000 Volts.
- Features AMP-LATCH series with gold over nickel contact plating for reliable connections.
- Suitable for 2.54 mm pitch ribbon cables with IDC termination type.
- Operates in a temperature range from -55°C to 125°C, suitable for harsh environments.
- The phosphor bronze contacts and polyethylene terephthalate housing provide durability and resistance.
- Right angle orientation supports space-efficient cable routing in assemblies.
- Ideal for industrial, electronic component assemblies, and PCB interconnections.
- Complies with no specific standards or approvals but offers robust mechanical and electrical performance.
Product Description
TE Connectivity 1-215911-4 IDC Connector is a specialized electronic component designed for robust cable interconnection solutions. Featuring 14 contacts arranged in 2 rows, this shrouded female connector provides a secure connection for 2.54 mm pitch ribbon cables commonly used in electronic assemblies and PCB connections.
The AMP-LATCH series connector offers gold over nickel plating on phosphor bronze contacts, ensuring enhanced conductivity and resistance to corrosion. Its housing is made of durable polyethylene terephthalate, providing mechanical strength and environmental protection.
Rated for a current of 1 Amp and a voltage capacity of up to 1000 Volts, this connector reliably supports signal and low power applications. Its operating temperature range from -55°C to 125°C enables use in demanding industrial and electronic environments.
The right angle orientation of the connector facilitates efficient cable management and integration into constrained spaces, making it suitable for electronic manufacturing, industrial automation, and laboratory equipment cabling.
The connector supports 14 contacts in 2 rows, enabling multi-line signal transmission. AMP-LATCH series design with IDC termination ensures fast and secure cable connections. Gold over nickel plating on contacts provides reliable electrical performance.
Supports operation at temperatures between -55°C and 125°C for durability. Phosphor bronze contact material and polyester housing enhance longevity. Right angle connector orientation improves assembly design flexibility.
Designed for ribbon cable applications with 2.54 mm pitch compatible with standard PCBs. No specific industry standards or approvals listed, ensuring focus on performance features.
This TE Connectivity IDC Connector is a quality component widely used in electronics production, test instruments, and industrial control panels. Browse TE Connectivity products and related electronic components on EnvMart for reliable solutions and additional connectors in your projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This IDC connector supports a current rating of 1 Ampere and a voltage capacity of up to 1000 Volts.
It operates within a temperature range of -55°C to 125°C, making it suitable for harsh environments.
This connector is designed for use with 2.54 mm pitch ribbon cables, utilizing IDC termination type.
The housing is made of polyethylene terephthalate, while the contacts are made from phosphor bronze with gold over nickel plating.
It features 14 contacts arranged in 2 rows.
The connector has a right angle orientation, which supports space-efficient cable routing in assemblies.
This connector does not comply with any specific industry standards or approvals, focusing instead on its performance features.
It is ideal for industrial, electronic component assemblies, and PCB interconnections.
This model uses IDC (Insulation Displacement Connector) termination type.
The AMP-LATCH series design ensures fast and secure cable connections, enhancing reliability in electronic assemblies.
The specific weight and dimensions are not provided; however, it is designed for compact integration into electronic assemblies.
It is designed for cable mounting, facilitating easy integration into various applications.
