HARWIN Archer M50 Series Straight Surface Pin Header, 10 Contacts, 1.27 mm Pitch, 2 Row, Unshrouded M50-3600542

HARWIN M50-3600542 Archer M50 Series Straight Surface Pin Header is a high-quality PCB header connector designed for efficient board-to-board and wire-to-board connectivity. With a precise 1.27 mm pitch and 10 male contacts arranged in 2 rows, this unshrouded surface mount connector features a nylon housing for mechanical strength and copper alloy contacts plated with gold for enhanced electrical performance. The connector supports currents up to 1A, making it suitable for low power signal transmission in sensitive electronic equipment.

Its straight orientation and surface mount design provide flexibility in PCB layout, and the connector can be cut to size for customized configurations. The tail pin length of 2.3 mm and mating pin length of 3 mm ensure secure soldering and mating connections. The operating temperature range extends from -40°C to 105°C, allowing reliable operation in demanding industrial and environmental conditions.

Typical applications include use in navigation systems, sonar and sensor displays, industrial and automotive control systems, test equipment, telecommunications, datacoms, and medical diagnostic and monitoring devices such as X-ray machines. The unshrouded design enables straightforward maintenance and easy access to the contacts, aligning with industry-standard Archer M50 series connectivity solutions.

Current rating of 1A for reliable low power performance. Durable nylon housing material for mechanical protection. Gold-plated copper alloy contacts ensuring excellent conductivity. Surface mount with straight orientation for versatile PCB assembly.

Wide operating temperature range of -40°C to 105°C ensuring robust operation. Supports board-to-board and wire-to-board connector systems. Unshrouded two-row design facilitates easy connection and modification. Tail pin length (2.3 mm) and mating pin length (3 mm) designed for optimal solder and mating reliability.

Compact and customizable connector length.

This pin header belongs to the category of PCB Headers in electronic components, particularly suitable for power and signal connectivity in various industrial, manufacturing, laboratory, and communications applications. Explore the HARWIN range at EnvMart for reliable PCB connector solutions.
