TE Connectivity PCB Power Relay, 6V dc Coil, 8A Switching Current, DPDT RX424006
Specifications
| Country of Origin | Austria |
|---|---|
| Brand | TE Connectivity |
| Dimensions | H 15.7mm, W 29.0mm, D 12.7mm |
| Height | 15.7mm |
| Length | 29mm |
| Model | RX424006 |
| Width | 12.7mm |
| Mount Type | PCB |
| Contact Material | Silver Nickel Alloy |
| Series | RX2 |
| Maximum Operating Temperature | 70°C |
| Contact Configuration | DPDT |
| Minimum Operating Temperature | -40°C |
| Switching Current | 8A |
| Terminal type | Solder |
| Standards/Approvals | VDE, RoHS, IEC 60335-1 |
| Coil Resistance | 68Ω |
| Coil Voltage | 6V dc |
| Switching AC Voltage | 400V ac |
| Coil Power | 250mW |
Key Features
- Coil voltage rated at 6V dc for efficient operation.
- Double Pole Double Throw (DPDT) contact configuration for versatile switching.
- Maximum switching current of 8A handling substantial loads.
- PCB mount type with solder terminal connections ensuring secure installation.
- Operation temperature range from -40°C to 70°C for industrial resilience.
- Silver Nickel Alloy contact material offering durability and reliable conductivity.
- Compact dimensions measuring 15.7mm height, 29mm length, and 12.7mm width.
- Complies with standards including VDE, RoHS, and IEC 60335-1 for safety and quality assurance.
Product Description
TE Connectivity RX424006 is a high-quality PCB power relay designed for reliable industrial and commercial applications. Featuring a 6V dc coil voltage and a DPDT (Double Pole Double Throw) contact configuration, this relay is engineered to handle a switching current of 8A, making it ideal for a wide array of electrical control tasks.
This relay is mounted on printed circuit boards using solder terminal types, facilitating secure and stable connections. It exhibits excellent thermal performance with an operating temperature range from -40°C to 70°C and a coil power consumption of just 250mW. The coil resistance is rated at 68 ohms, supporting efficient coil energization.
Constructed with durable Silver Nickel Alloy contacts, the RX424006 ensures enhanced conductivity and longevity. Its compact form factor with dimensions H 15.7mm, W 29.0mm, D 12.7mm allows for space-saving integration in circuits. The relay complies with stringent international standards such as VDE, RoHS, and IEC 60335-1, confirming its adherence to safety and environmental norms.
Typical applications include domestic appliances, heating control, emergency lighting systems, and automatic door controls. The flux-proof construction ensures reliable operation even in environments prone to flux residue, enhancing performance consistency.
Coil voltage rated at 6V dc for efficient operation. DPDT contact configuration provides versatile switching options. Handles switching current up to 8A for substantial load requirements. PCB mount type ensures easy installation and solder terminal connections.
Operating temperature ranges from -40°C to 70°C suitable for various conditions. Silver Nickel Alloy contacts guarantee durability and optimal conductivity. Compact dimensions enable space-saving design integration. Meets VDE, RoHS, and IEC 60335-1 standards ensuring compliance and safety.
EnvMart offers this TE Connectivity PCB Power Relay for industrial, laboratory, manufacturing, HVAC, and commercial electrical control applications. For more power relay solutions, browse our Electronics & Electricals > Relays & Contactors > Power Relay category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The coil voltage of this relay is rated at 6V dc, which supports efficient operation.
This model can handle a maximum switching current of 8A, making it suitable for substantial load requirements.
The RX424006 features a Double Pole Double Throw (DPDT) contact configuration, allowing for versatile switching options.
The dimensions of this relay are 15.7mm in height, 29mm in length, and 12.7mm in width.
The operating temperature range for this relay is from -40°C to 70°C, suitable for various industrial conditions.
The contacts of this relay are made from Silver Nickel Alloy, which ensures durability and reliable conductivity.
This relay is designed for PCB mounting and features solder terminal connections for secure installation.
This relay complies with several standards including VDE, RoHS, and IEC 60335-1, ensuring safety and quality assurance.
The coil resistance of the RX424006 is rated at 68 ohms, supporting efficient coil energization.
The coil power consumption of this relay is 250mW, which contributes to its efficient operation.
Typical applications for this relay include domestic appliances, heating control, emergency lighting systems, and automatic door controls.
This relay can switch AC voltages up to 400V ac, making it versatile for various electrical control tasks.
