TRACOPOWER High-Efficiency Dual Output Surface Mount DC/DC Converter TES 3-2422WI 36V Input, 12V ±12V Output, 125mA, 3W
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | Converters / DC-DC Converters TRACOPOWER TES 3WI DC/DC Converter, 12V dc/ 125 mA |
| Brand | TRACOPOWER |
| Efficiency | 81% |
| Length | 32.3mm |
| Model | TES 3-2422WI |
| Depth | 9.7mm |
| Mount Type | Surface |
| Series | TES 3WI |
| Maximum Operating Temperature | 70°C |
| Package Type | Surface Mount |
| Minimum Operating Temperature | -40°C |
| MTBF | 1000000h |
| Number of outputs | 2 |
| Maximum Output Power | 3W |
| Maximum Input Voltage | 36V dc |
| Minimum Input Voltage | 9V |
| Number of Pins | 24 |
| Output Voltage 1 | 12V dc |
| Output Current 1 | 125mA |
| Isolation Voltage | 1.5kV dc |
| Input Ratio | 4:1 |
| Output Voltage 2 | -12V dc |
| Ultra-wide 4 | 1 input voltage range |
| Input Ratio4 | 1 |
Key Features
- Compact low profile surface mount package measuring 32.3mm x 9.7mm.
- Provides isolated dual outputs at 12V and -12V dc, each delivering up to 125mA current.
- High efficiency of 81% ensures low power loss and thermal performance.
- Operating temperature range from -40°C to +70°C suitable for industrial environments.
- 1.5kV dc input/output isolation for reliable voltage separation and safety.
- Incorporates short circuit protection and meets EMC standards with input filtering for EN 55022 Class A.
- Constructed with UL94V-0 rated package material qualified for lead-free reflow soldering.
- MTBF rating of 1,000,000 hours reflecting high reliability.
Product Description
TRACOPOWER TES 3-2422WI is a premium 3W dual output regulated isolated DC/DC converter module designed for surface mount applications. This compact high-efficiency converter supports a wide 4:1 input voltage range from 9V to 36V dc, accommodating varying supply voltages and surges.
The unit delivers isolated ±12V dc dual outputs each rated at 125mA, ideal for powering sensitive electronics requiring symmetrical bipolar supply. Designed with robust features such as 1.5kV dc isolation, short circuit protection, and an input filter to ensure electromagnetic compatibility according to EN 55022 Class A.
The small form factor with length 32.3mm and depth 9.7mm fits compact electronic designs, and UL94V-0 compliant material assures safety and flame retardancy in industrial or commercial use.
The converter operates reliably across a wide temperature range of -40°C to +70°C, making it suitable for harsh industrial, laboratory, and automotive power conversion applications.
It has a mean time between failures (MTBF) exceeding 1,000,000 hours demonstrating excellent reliability for critical system components. Compact dual output surface mount DC/DC power converter module. Wide 4:1 input voltage range with 9V to 36V dc compatibility.
Outputs ±12V dc at 125mA each for bipolar power supply needs. High efficiency rating of 81% reduces thermal stress. 1.5kV dc input/output isolation for safety and noise reduction. Short circuit protection and EMC input filter included.
UL94V-0 flame retardant package suitable for lead-free soldering. Operating temperatures from -40°C up to 70°C for broad environment use. MTBF of 1,000,000 hours for superior system reliability.
This TRACOPOWER DC/DC converter is well suited for industrial automation, instrumentation, telecommunications, and embedded systems requiring compact isolated power modules. Select TES 3-2422WI for dependable and precise DC voltage conversion in demanding applications.
Explore more DC/DC Converters and power supply modules on EnvMart to find tailored solutions for your project needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a wide input voltage range from 9V to 36V dc, accommodating varying supply voltages and surges.
It provides isolated dual outputs of ±12V dc, each capable of delivering up to 125mA current.
The efficiency rating is 81%, which helps reduce power loss and thermal stress.
It features an isolation voltage of 1.5kV dc, ensuring reliable voltage separation and safety.
This unit operates reliably within a temperature range of -40°C to +70°C, suitable for harsh environments.
The surface mount package measures 32.3mm in length and 9.7mm in depth, making it suitable for compact electronic designs.
It incorporates short circuit protection to enhance safety during operation.
This model has two outputs, providing both positive and negative voltage supplies.
It meets EMC standards with input filtering for EN 55022 Class A, ensuring electromagnetic compatibility.
The MTBF is rated at 1,000,000 hours, indicating high reliability for critical applications.
It is constructed with UL94V-0 rated package material, which is qualified for lead-free reflow soldering.
It is well suited for industrial automation, instrumentation, telecommunications, and embedded systems requiring compact isolated power modules.
