HARWIN M180 Female Connector Housing 2 mm Pitch 20 Way 2 Row Straight M80-8802098

Free Delivery in India | Lowest Global Shipping Charges

HARWIN M180 Female Connector Housing 2 mm Pitch 20 Way 2 Row Straight M80-8802098

Name: HARWIN M180 Female Connector Housing 2 mm Pitch 20 Way 2 Row Straight M80-8802098
Brand: HARWIN
SKU: 122873



Category Connector Housing Brand HARWIN Condition New

Specifications

Country of Origin	United Kingdom
Brand	HARWIN
Orientation	Straight
Length	26.3mm
Model	M80-8802098
Width	7.71mm
Mount Type	Cable
Housing Material	Fibreglass Reinforced Polystyrene
Series	M180
Number of Rows	2
Pitch	2mm
For Use With	Board-In Connector, Crimp Connector
Number of Contacts	20
Connector Gender	Female

Key Features

The connector features a length of 26.3 mm and width of 7.71 mm.
It is constructed from fibreglass reinforced polystyrene housing material.
This high reliability M180 series housing is ideal for harsh environments with safety-critical applications.
The female gender design allows mating with corresponding male connectors in the Datamate range.
It offers polarised mouldings and is suited for commercial off-the-shelf (COTS) applications.
The connector complies with standards BS9525-F0033, MIL C 55302, and CEC 75101-008.
It supports high vibration, shock, and acceleration conditions without degradation of connection integrity.
The product is manufactured in the United Kingdom and comes in a production pack (bag) packaging type.

Product Description

HARWIN M80-8802098 is a Female Connector Housing from the M180 series, featuring a 2 mm pitch and 20 way, 2 row straight configuration. Designed for cable mounting, it is compatible with both board-in and crimp connectors. The housing measures 26.3 mm in length and 7.71 mm in width, constructed from durable fibreglass reinforced polystyrene material.

This connector housing is part of the high reliability Datamate range, which is engineered for safety-critical applications and environments subjected to high vibration, shock, and acceleration. The use of high reliability four finger Beryllium Copper contacts in the Datamate series ensures strong mechanical and electrical connection, with a four finger clip design providing secure retention under severe conditions.

The polarised mouldings guarantee correct mating to prevent misconnection. This product complies with BS9525-F0033, MIL C 55302, and CEC 75101-008 standards, affirming its suitability for demanding industrial and commercial uses.

Applications include industrial, manufacturing, aerospace, and telecommunications sectors requiring robust cable-to-board connectivity solutions. Its compatibility with known industry equivalent connectors simplifies integration into existing systems. The housing is supplied in production packs, enhancing assembly line efficiency.

The connector is a 20 contact, 2 row female housing with a 2 mm pitch. Durable fibreglass reinforced polystyrene housing ensures longevity in harsh conditions. Designed for cable mounting and used with board-in and crimp connectors.

Meets industry standards including BS9525-F0033, MIL C 55302, and CEC 75101-008. Part of the Datamate series with high reliability beryllium copper contact clips. Suitable for high vibration and shock environments. Manufactured in the United Kingdom for trusted quality assurance.

Available in production pack (bag) packaging to aid manufacturing efficiency.

This HARWIN M180 Female Connector Housing is an ideal choice for electronics assemblies requiring robust and secure connections in industrial, automotive, aerospace, and high-reliability applications. Discover more products in the Connector Housing category on EnvMart for your electronic component needs.
