HARWIN Datamate L-Tek Series Straight Through Hole PCB Header 12 Contacts 2 mm Pitch 2 Row Shrouded M80-8541242

Free Delivery in India | Lowest Global Shipping Charges

HARWIN Datamate L-Tek Series Straight Through Hole PCB Header 12 Contacts 2 mm Pitch 2 Row Shrouded M80-8541242

Name: HARWIN Datamate L-Tek Series Straight Through Hole PCB Header 12 Contacts 2 mm Pitch 2 Row Shrouded M80-8541242
Brand: HARWIN
SKU: 122835



Category PCB Headers Brand HARWIN Condition New

Specifications

Country of Origin	United Kingdom
Voltage	120V
Brand	HARWIN
Orientation	Straight
Current	3A
Model	M80-8541242
Mount Type	Through Hole
Housing Material	Polyphenylene Sulphide
Contact Material	Phosphor Bronze
Series	Datamate L-Tek
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	2mm
Contact Plating	Gold
Number of Contacts	12
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Board-to-Board, Wire-to-Board
Tail Pin Length	3mm

Key Features

This through hole header supports a current rating of 3 A.
Housing is made from durable polyphenylene sulphide for high reliability in harsh environments.
Contacts are phosphor bronze with gold plating to ensure excellent conductivity and corrosion resistance.
Designed for board-to-board and wire-to-board connector systems.
Supports a voltage rating of 120 V with operating temperatures from -55°C to 125°C.
The tail pin length is 3 mm for solder termination on PCB.
Its straight orientation and 2-row configuration suit compact PCB designs.
Complies with industry standards including BS9525-F0033, MIL C 55302, and CEC 75101-008.

Product Description

HARWIN M80-8541242 PCB Header from the Datamate L-Tek Series is a straight through hole connector designed for high-reliability electronic applications requiring durable and secure connections. It features 12 male contacts arranged in two rows with a 2 mm pitch, shrouded for safety and mechanical protection.

This header supports a current rating of 3 A and voltage up to 120 V, making it suitable for various industrial, commercial, and aerospace applications. The housing material is polyphenylene sulphide, known for its excellent thermal and chemical resistance, supporting operating temperatures ranging from -55°C to 125°C.

The gold-plated phosphor bronze contacts with beryllium copper four-finger clips ensure long-lasting, low-resistance connections capable of withstanding numerous mating cycles without degradation. The 3 mm tail pin length enables secure soldered connection to printed circuit boards using through hole mount technology.

This connector is ideal for board-to-board and wire-to-board applications, especially in environments subject to vibration, shock, or harsh conditions. It meets several rigorous standards such as BS9525-F0033, MIL C 55302, and CEC 75101-008, assuring quality and reliability.

Made in the United Kingdom, this product serves electronics manufacturing sectors including industrial control, aerospace, defense, telecommunications, and laboratory instrumentation.

This PCB header features a 2-row, 12 contact configuration with 2 mm pitch. Constructed with polyphenylene sulphide housing material to resist harsh environments. Contacts of phosphor bronze plated with gold enhance conductivity and durability.

Suitable for board-to-board and wire-to-board connector systems. Rated for 3 A current and 120 V voltage. Operation range from -55°C up to 125°C ensures wide applicability. Shrouded design provides mechanical protection and polarization.

Tail pin length of 3 mm for robust through hole soldering. Complies with international industry standards for high reliability. Explore the full range of high-quality PCB Headers by HARWIN on EnvMart to find connectors tailored for your specific electronic assembly needs.
