HARWIN Through Hole Board-to-Board PCB Socket 10-Contact, 2 Row, 2 mm Pitch, 12A, 120V, Nylon Housing, Gold M80-8501045
Specifications
| Country of Origin | United Kingdom |
|---|---|
| Voltage | 120V |
| Brand | HARWIN |
| Orientation | Straight |
| Current | 12A |
| Model | M80-8501045 |
| Mount Type | Through Hole |
| Housing Material | Nylon |
| Contact Material | Beryllium Copper Alloy, Brass |
| Series | M80 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Board-to-Board |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2mm |
| Contact Plating | Gold |
| Number of Contacts | 10 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
Key Features
- Supports up to 12A current and 120V voltage rating.
- Constructed with durable nylon housing for long-lasting performance.
- High-quality gold plated beryllium copper alloy and brass contacts ensure excellent conductivity.
- Designed for board-to-board connector systems with straight orientation and solder termination.
- Operates reliably in temperature ranges from -55°C to 125°C.
- Features female contact gender and complies with industrial standards for harsh environment use.
- Ideal for applications requiring vibration and shock resistance with high mating cycle durability.
- Polarised mouldings and high reliability four-finger contacts ensure connection integrity.
Product Description
HARWIN M80-8501045 Through Hole Board-to-Board PCB Socket is engineered for high-performance electronic component interconnections, featuring 10 contacts arranged in 2 rows with a precise 2 mm pitch.
This connector supports up to 12A current and 120V voltage, making it suitable for various industrial and commercial electronic applications. Its nylon housing provides excellent mechanical stability and electrical insulation under demanding conditions.
The contacts are made of beryllium copper alloy and brass with gold plating, offering superior conductivity and resistance to corrosion while maintaining a low insertion force. This socket is designed for through-hole mounting with a straight orientation for seamless integration onto PCBs.
Operating reliably across a wide temperature range of -55°C to 125°C, the M80 series socket fits applications subject to harsh environments, vibration, and shock. Its high reliability four-finger contact system ensures connection stability over numerous mating cycles.
Polarised mouldings prevent incorrect mating, and this series mates with known industry equivalents, ideal for commercial off-the-shelf (COTS) applications. The socket is RoHS compliant and meets several industrial standards including BS9525-F0033 and MIL C 55302.
Supports 10 female contacts in 2 rows and 2 mm pitch. Solder termination with through-hole mount type. Nylon housing engineered for mechanical and electrical robustness. Gold plated beryllium copper alloy contacts for high conductivity.
Rated for 12A current and 120V voltage. Wide operating temperature from -55°C to 125°C. Polarised mouldings and high mating cycle durability. Suitable for harsh industrial, commercial, and electronic manufacturing applications.
HARWIN offers trusted connector solutions widely used in industrial electronics, laboratory equipment, manufacturing, and other sectors requiring reliable PCB interconnections. Browse the PCB Socket category to discover more options from leading brands at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This PCB socket supports a maximum current of 12A and a voltage rating of 120V.
The contacts are arranged in a 2 mm pitch with a total of 10 contacts in 2 rows.
The contacts are made from a beryllium copper alloy and brass, while the housing is constructed from nylon.
It operates reliably within a temperature range of -55°C to 125°C.
This model features solder termination and is designed for through-hole mounting.
Yes, it includes polarised mouldings to prevent incorrect mating during installation.
It is designed as a board-to-board connector system.
The contacts in this socket are female.
It complies with several industrial standards, including BS9525-F0033 and MIL C 55302.
This model has a straight orientation for easy integration onto PCBs.
The gold plating on the contacts ensures excellent conductivity and resistance to corrosion.
The country of origin for this model is the United Kingdom.
