TE Connectivity VAL-U-LOK Series Right Angle Through Hole PCB Header, 4 Contact, 4.2 mm Pitch, 2 Row, Shrouded 1586043-4
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 600V |
| Brand | TE Connectivity |
| Orientation | Right Angle |
| Current | 9A |
| Mount Type | Through Hole |
| Housing Material | Nylon |
| Contact Material | Brass |
| Series | VAL-U-LOK |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pitch | 4.2mm |
| Contact Plating | Tin |
| Number of Contacts | 4 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 3.5mm |
Key Features
- Constructed with durable nylon housing ensuring heat resistance and insulation.
- Gold plated brass male contacts provide secure electrical connectivity.
- Designed with a 4.2 mm pitch and two rows for compact and reliable PCB mounting.
- Shrouded and right angle orientation supports easy mating and positive latching alignment.
- Rated for 9A current and capable of withstanding voltages up to 600V.
- Suitable for through-hole mounting with solder termination type offering robust mechanical stability.
- Operates reliably within temperature range -40°C to 105°C.
- Compliant with UL94V-2 housing material standards for flame retardancy.
Product Description
TE Connectivity 1586043-4 VAL-U-LOK Series Right Angle Through Hole PCB Header features 4 contacts arranged in 2 rows with a 4.2 mm pitch and shrouded design for enhanced protection and secure connections. It is designed for wire-to-board applications requiring reliable, easy mate/unmate connectors with positive latching and keying to ensure proper alignment.
The connector housing is made from UL94V-2 rated natural nylon, providing excellent heat resistance and electrical insulation. The contacts are brass with tin plating, optimized for solder termination to the PCB. The right-angle orientation is ideal for space-constrained applications where horizontal PCB board mounting is required.
Rated to handle up to 9A current and 600V voltage, this connector operates efficiently within the temperature range of -40°C to 105°C. Its design includes optional mounting features such as screw mounting for secure fixture. This PCB header supports through-hole soldering, ensuring strong mechanical and electrical connections in complex circuit assemblies.
Typical applications include industrial electronics, power distribution, control systems, and general PCB interfacing where durable, high-performance connectors are essential. The VAL-U-LOK series is known for ease of use, durability and precise contact alignment for consistent signal integrity.
Durable nylon housing rated UL94V-2 for flame retardancy. Brass contacts with tin plating ensure reliable conductivity. 4.2 mm pitch, 2-row configuration for compact PCB footprint. Shrouded design with positive latching to prevent mismating.
Right angle orientation supports horizontal board mounting. Through hole solder termination for strong, durable connections. Voltage rating up to 600V and current rating of 9A. Operates between -40°C to 105°C for wide environmental tolerance.
Suitable for industrial, power and electronic PCB assemblies. Explore more TE Connectivity products and PCB headers at EnvMart for reliable electronic component solutions.
Explore more products in our PCB Connectors & Wire Housings category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for a maximum current of 9A.
It is capable of withstanding voltages up to 600V.
The contacts are arranged with a pitch of 4.2 mm.
This connector features 4 contacts arranged in 2 rows.
The housing is made from nylon, while the contacts are brass with tin plating.
It operates reliably within a temperature range of -40°C to 105°C.
It uses solder termination for secure connections.
This model features a right angle orientation, suitable for horizontal PCB mounting.
The connector is designed with a shrouded configuration for enhanced protection.
The country of origin for this product is India.
It is suitable for industrial electronics, power distribution, control systems, and general PCB interfacing.
The tail pin length is 3.5 mm.
