STMicroelectronics 1-Element Bi-Directional Transil TVS Diode 600 W, Surface Mount DO-214AA SM6T100CA
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 2.45mm |
| Length | 4.6mm |
| Model | SM6T100CA |
| Width | 3.95mm |
| Mount Type | Surface |
| Series | SM6T |
| Maximum Operating Temperature | 150°C |
| Package Type | DO-214AA (SMB) |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Clamping Voltage VC | 178V |
| Diode Configuration | Single |
| Direction Type | Bi-Directional |
| Minimum Breakdown Voltage Vbr | 95V |
| Maximum Reverse Stand-off Voltage Vwm | 85.5V |
| Peak Pulse Power Dissipation Pppm | 600W |
| Test Current It | 1mA |
| Maximum Peak Pulse Current Ippm | 22.5A |
| Maximum Reverse Leakage Current | 200nA |
Key Features
- Bi-directional diode configuration ensures protection from voltage transients on both polarities.
- Minimum breakdown voltage of 95 V and maximum reverse stand-off voltage of 85.5 V.
- Clamping voltage of 178 V providing effective transient voltage suppression.
- Maximum peak pulse current rating of 22.5 A with low maximum reverse leakage current of 200 nA.
- Operates reliably within temperature range of -55°C to 150°C.
- Surface mount device suitable for automated PCB assembly.
- Single element per chip for robust transient suppression.
- No automotive standards compliance, designed primarily for general electronics and industrial applications.
Product Description
STMicroelectronics SM6T100CA is a high reliability 1-element bi-directional Transil™ TVS diode designed for transient voltage suppression, delivering a peak pulse power dissipation of 600 W in a compact DO-214AA (SMB) surface mount package. It protects circuits from voltage spikes and electrostatic discharge by clamping voltage transients and safeguarding sensitive semiconductor devices in electronic systems.
The diode features a minimum breakdown voltage (Vbr) of 95 V and can withstand a maximum reverse stand-off voltage (Vwm) of 85.5 V, ensuring stable and reliable operation under transient events. Its clamping voltage (Vc) of 178 V effectively limits the voltage spikes to safe levels, while a maximum peak pulse current (Ippm) of 22.5 A allows handling of high energy surges.
Operating temperature ranges from -55°C to 150°C, meeting demanding environmental conditions in industrial, consumer electronics, and power supply applications. The device's low maximum reverse leakage current of 200 nA minimizes load current during normal operation, enhancing circuit efficiency.
With a pin count of 2 and a small form factor measuring 4.6 mm length, 3.95 mm width, and 2.45 mm height, the SM6T100CA is optimized for surface mounting on PCBs, facilitating automated assembly for production efficiency. The single element design per chip provides robust protection in bi-directional transient voltage suppression applications.
This product is suitable for a wide range of uses including electronics manufacturing, power supply protection, industrial control systems, telecommunications equipment, and other commercial electronic devices requiring reliable transient voltage suppression.
Bi-directional transient voltage suppression. 600 W peak pulse power capacity for surge protection. Compact surface mount DO-214AA package for automated assembly. Wide operating temperature range from -55°C to 150°C. Low leakage current ensures efficiency and minimal impact on circuits.
Designed for industrial, commercial, and power electronics applications. Explore more STMicroelectronics TVS diode products on EnvMart for comprehensive circuit protection solutions.
Explore more products in our TVS Diodes category.
