TE Connectivity Miniature SPDT PCB Power Relay 12V DC Coil Voltage 10A Switching Current Silver Alloy Contacts PB114012
Specifications
| Country of Origin | India |
|---|---|
| Brand | TE Connectivity |
| Height | 20mm |
| Length | 15mm |
| Model | PB114012 |
| Width | 15mm |
| Mount Type | PCB |
| Contact Material | Silver Alloy |
| Series | PB |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | SPDT |
| Minimum Operating Temperature | -40°C |
| Switching Current | 10A |
| Terminal type | Solder |
| Standards/Approvals | VDE, cULus |
| ANSI/ESD S20.20 | 2014 |
| BS EN 61340-5-1 | 2007 |
| Coil Resistance | 400Ω |
| Coil Voltage | 12V dc |
| Switching AC Voltage | 400V ac |
| Coil Power | 360mW |
Key Features
- This relay uses a compact, through-hole mount design suitable for PCB mounting.
- It offers a coil power consumption of 360 milliwatts providing efficient operation.
- The contact material is silver alloy with nickel silver, cadmium-free contacts ensuring durability.
- Operating temperature range spans from -40°C up to 85°C, suitable for various environmental conditions.
- The coil resistance is 400 ohms, providing stable coil energization characteristics.
- It can handle switching AC voltage up to 400V and switching power of 2.5kVA.
- The relay complies with industry standards including VDE and cULus certifications.
- Ideal for heating and temperature controllers as well as small home appliances.
Product Description
TE Connectivity PB114012 miniature single pole double throw (SPDT) PCB power relay operates with a 12V DC coil voltage and supports a 10A switching current, ensuring reliable switching in electronic circuits.
This relay is designed for through-hole PCB mounting featuring a compact form factor with dimensions of 15mm length, 15mm width, and 20mm height. It uses silver alloy contacts that are nickel silver 90/10 cadmium-free for long life and resistance to corrosion.
With coil power consumption at 360 milliwatts and coil resistance of 400 ohms, this relay offers energy efficiency and reliable coil activation. It provides electrical isolation of 2.5kV RMS between coil and contact, enhancing safety and signal integrity.
The relay's operating temperature range from -40°C to 85°C allows it to be used in industrial and commercial environments. It supports switching AC voltages up to 400V AC and switching power rating of 2.5kVA suitable for various power loads.
Typical applications include heating and temperature controllers and usage in small home appliances, where compact size and reliable switching are critical. This relay uses a compact, through-hole mount design suitable for PCB mounting.
It offers a coil power consumption of 360 milliwatts providing efficient operation. The contact material is silver alloy with nickel silver, cadmium-free contacts ensuring durability. Operating temperature range spans from -40°C up to 85°C, suitable for various environmental conditions.
The coil resistance is 400 ohms, providing stable coil energization characteristics. It can handle switching AC voltage up to 400V and switching power of 2.5kVA. Mechanical dimensions are compact: Length 15mm, Width 15mm, and Height 20mm.
The relay complies with industry standards including VDE and cULus certifications. Ideal for heating and temperature controllers as well as small home appliances. This product suits industrial, laboratory, HVAC, manufacturing, and commercial applications requiring robust relay components.
