TE Connectivity 40-Way IDC Connector Male for Cable, 2 Row, 2.54mm Pitch, 1A, 250V, AMP-LATCH 622 Series 1-1658525-3

TE Connectivity 1-1658525-3 40-Way IDC Connector Male is a high-quality IDC DIP plug ribbon cable connector featuring 40 contacts arranged in 2 rows with a 2.54 mm pitch, designed for dependable and easy wiring in electronic and industrial equipment. It accommodates 26 to 28 AWG PVC insulated ribbon cables and provides a current rating of 1A at 250V, suitable for signal and low power connections.

The connector is shrouded and designed with male contacts plated with tin over nickel to ensure long-term corrosion resistance and reliable electrical contact. The housing is manufactured from polyethylene terephthalate (PET) which is UL 94V-0 rated, offering ruggedness and flame retardant properties for industrial safety. Operating temperature ranges from -55°C to 125°C, enabling stable performance under harsh environmental conditions.

Part of the AMP-LATCH 622 series, this IDC connector is engineered to allow cable crimping either before or after soldering the connector to the Printed Circuit Board (PCB). Its right angle orientation and a compact height of 8.97 mm cater to versatile PCB designs and tight spaces.

Rugged glass reinforced thermoplastic construction ensures mechanical durability suitable for industrial, manufacturing, and electronics assembly applications. Suitable universal hand tools and dies (RS Stock No. 462-975 and 463-013) are recommended for crimping during installation.

Supports 40 contacts with 2-row configuration for increased connectivity. IDC termination type for easy and secure ribbon cable termination. Beryllium copper contact material provides excellent conductivity and durability.

Tin over nickel plating protects contacts from corrosion. Housing material PET is flame retardant and robust. Operating temperature from -55°C to 125°C for diverse environments. Voltage rating of 250V and current rating of 1A ensures safe electrical performance.

Right angle cable mount type enables flexible cabling options. Part of AMP-LATCH 622 series for compatibility and reliability. Compact height of 8.97 mm suits dense PCB assemblies.

This IDC connector is ideal for industrial automation, electronics manufacture, communication equipment, and other applications requiring dependable multi-contact cable connections. Browse related IDC Connectors and cable assembly components at EnvMart.
