STMicroelectronics Operational Amplifier Dual Channel 8-Pin SOIC 4 MHz Gain Bandwidth TS922AID
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 1.25mm |
| Length | 4.9mm |
| Model | TS922AID |
| Width | 3.9mm |
| Mount Type | Surface |
| Low Noise | 9 nV/√Hz |
| Series | TS922A |
| Output Current | 80mA |
| Maximum Operating Temperature | 125°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 2 |
| Standards/Approvals | RoHS |
| Pin Count | 8 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 12V |
| Minimum Supply Voltage | 3V |
| GBP - Gain Bandwidth Product | 4MHz |
| Input Bias Current | 100 nA |
| Vos - Input Offset Voltage | 1.8 mV |
| Slew Rate | 1.3V/μs |
| High output current | 80 mA (able to drive 32 Ω loads) |
| Input Offset Current | 30 nA |
Key Features
- Optimized dual channel operational amplifier for 3V to 12V supply voltages.
- Gain bandwidth product of 4 MHz supports high-speed applications.
- High output current of up to 80 mA suitable for driving 32 Ω loads.
- Low input bias current of 100 nA and input offset voltage of 1.8 mV.
- Fast slew rate of 1.3 V/μs ensures precise signal amplification.
- Operates over a wide temperature range from -40°C to 125°C.
- Complies with RoHS and AEC-Q100 automotive quality standards.
- Compact surface mount 8-pin SOIC package with small footprint.
Product Description
STMicroelectronics TS922AID is a high-performance dual operational amplifier with a gain bandwidth product of 4 MHz and supplied in a compact 8-pin SOIC surface-mount package. Designed for power supply operation between 3V and 12V, it delivers excellent audio performance with low distortion and noise, making it suitable for precise analog signal conditioning.
The device features a maximum output current of 80 mA, enabling it to drive low impedance loads such as 32 Ω speakers efficiently. It operates reliably across a wide temperature range from -40°C to 125°C conforming to AEC-Q100 automotive quality standards. Low input bias currents of 100 nA and minimal input offset voltage of 1.8 mV contribute to its high accuracy and stability in precision applications.
This operational amplifier exhibits a fast slew rate of 1.3 V/μs, supporting a broad range of industrial, consumer, and automotive electronics use cases including audio amplification, sensor signal processing, and analog computation. Its small footprint with dimensions 4.9mm length, 3.9mm width, and 1.25mm height enables high-density PCB layouts for compact designs.
Dual channel BiCMOS technology Operational Amplifier. Wide supply voltage range from 3V to 12V. High output current of up to 80 mA for demanding load drive capability. Low distortion and noise performance for high fidelity signal handling.
Compliant with RoHS and automotive AEC-Q100 standards. Compact SOIC 8-pin package dimensions for surface mount applications.
This amplifier is ideal for use in industrial, automotive, audio, and measurement systems where precise low noise amplification is critical. Its rugged design and automotive qualification ensure long term reliability in harsh operating environments. Explore more electronic components and semiconductors on EnvMart for your circuit design and manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of the TS922AID operational amplifier is 4 MHz, which supports high-speed applications.
The TS922AID operates with supply voltages ranging from 3V to 12V.
The dimensions of this model are 4.9 mm in length, 3.9 mm in width, and 1.25 mm in height.
The input bias current for the TS922AID is 100 nA, contributing to its high accuracy.
This operational amplifier operates over a wide temperature range from -40°C to 125°C.
The slew rate of this model is 1.3 V/μs, allowing for precise signal amplification.
The TS922AID is supplied in a compact 8-pin SOIC surface-mount package.
This operational amplifier complies with the AEC-Q100 automotive quality standards.
The input offset voltage for the TS922AID is 1.8 mV, which helps maintain precision in applications.
This model features low noise performance with a noise level of 9 nV/√Hz, suitable for high fidelity signal handling.
Yes, the TS922AID is compliant with RoHS standards, ensuring it meets environmental regulations.
