STMicroelectronics Operational Amplifier 1.3 MHz Gain Bandwidth, 6V SOT-23 5-Pin LMV321RILT
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 1.3mm |
| Length | 3mm |
| Model | LMV321RILT |
| Width | 1.75mm |
| Mount Type | Surface |
| Series | LMV321 |
| Output Current | 46mA |
| Maximum Operating Temperature | 125°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 1 |
| Standards/Approvals | RoHS |
| Pin Count | 5 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 6V |
| Minimum Supply Voltage | 3V |
| GBP - Gain Bandwidth Product | 1.3MHz |
| Input Bias Current | 95 nA |
| Vos - Input Offset Voltage | 6 mV |
| Slew Rate | 0.45V/μs |
| Input Offset Current | 25 nA |
| Low supply current | 145 μA |
| Gain bandwidth product | 1 MHz |
| Electrostatic Discharge (ESD) tolerance | 2 kV |
Key Features
- Supports a supply voltage range from 3 V to 6 V.
- Low supply current of 145 microamps for power-sensitive applications.
- Rail-to-rail input and output performance ensures full voltage swing.
- High electrostatic discharge tolerance of 2 kV for robust operation.
- Operates within -40°C to 125°C temperature range.
- Input bias current of 95 nA and output current capability of 46 mA.
- Adheres to RoHS standards and automotive AEC-Q100 certification.
- Low input offset voltage of 6 mV and input offset current of 25 nA for precision.
Product Description
STMicroelectronics LMV321RILT is a single-channel operational amplifier designed for low power consumption and precision performance. This device supports supply voltages from 3 V up to 6 V and is housed in a compact 5-pin SOT-23 surface mount package with dimensions 3mm length, 1.75mm width, and 1.3mm height.
The operational amplifier offers rail-to-rail input and output, facilitating a full voltage swing and making it ideal for battery-powered and portable equipment applications. It features a gain bandwidth product of 1.3 MHz and a typical low supply current of 145 microamps, optimizing both speed and power efficiency.
The LMV321RILT delivers an output current up to 46 mA and tolerates electrostatic discharges up to 2 kV, ensuring robust operation in industrial and automotive environments. Its input offset voltage is as low as 6 mV with an input offset current of 25 nA, contributing to stable, accurate signal amplification.
Operating temperature range from -40°C to 125°C makes this amplifier suitable for harsh environmental conditions. The device complies with RoHS regulations and meets the automotive standard AEC-Q100.
Supply voltage from 3 V to 6 V. Gain bandwidth product of 1.3 MHz. Low supply current of 145 μA supports battery-operated devices. Rail-to-rail input/output for enhanced dynamic range. Electrostatic discharge tolerance of 2 kV.
Operating temperature range from -40°C to 125°C. Compact 5-pin SOT-23 package: 3 x 1.75 x 1.3 mm. Output current up to 46 mA. Automotive standard certified AEC-Q100 compliant. Low offset voltage and input bias current for precision amplification.
The LMV321RILT Operational Amplifier is widely applicable in industrial instrumentation, automotive electronics, portable instrumentation, consumer devices, and precision analog signal conditioning. EnvMart offers this highly reliable and efficient amplifier as part of its extensive electronics component range.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of this operational amplifier is 1.3 MHz.
It supports a supply voltage range from 3 V to 6 V.
This operational amplifier can deliver an output current of up to 46 mA.
The SOT-23 package dimensions are 3 mm in length, 1.75 mm in width, and 1.3 mm in height.
The LMV321RILT operates within a temperature range of -40°C to 125°C.
It has a low input offset voltage of 6 mV.
The operational amplifier has an electrostatic discharge tolerance of 2 kV.
The input bias current for this amplifier is 95 nA.
This model is designed for surface mount installation.
It adheres to RoHS standards and is certified to the automotive AEC-Q100 standard.
The typical supply current is 145 microamps, making it suitable for power-sensitive applications.
This operational amplifier is a single-channel device.
