Abracon 32MHz Crystal Oscillator ±20 ppm HCMOS 4-Pin Surface Mount FO7HHAAE32.0-T1
Specifications
| Country of Origin | India |
|---|---|
| Brand | Abracon |
| Height | 5mm |
| Length | 7mm |
| Model | FO7HHAAE32.0-T1 |
| Packaging | Tape & Reel |
| Width | 5.2mm |
| Mount Type | Surface |
| Series | FO7HH |
| Maximum Operating Temperature | 85°C |
| Output Frequency | 32MHz |
| Package Type | Surface Mount |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | RoHS |
| Pin Count | 4 |
| Maximum Supply Voltage | 5V |
| Oscillator Type | Crystal Oscillator |
| Output Level | HCMOS |
Key Features
- Operates with a supply voltage of 5V ±10% for reliable performance.
- Functional temperature range from -40°C to +85°C suitable for diverse environments.
- Compact dimensions of 7mm length, 5.2mm width, and 5mm height for circuit board integration.
- Stable oscillation frequency of 32MHz with fast start-up time of 10 milliseconds.
- Lead (Pb) free construction compliant with RoHS standards for environmental safety.
- Designed with a maximum soldering temperature of 260°C and maximum soldering time of 10 seconds x 2.
- Ideal for industrial, electronic manufacturing, communication, and automotive applications requiring precise timing.
- Package type includes tape & reel format facilitating automated assembly processes.
Product Description
Abracon FO7HHAAE32.0-T1 is a precision 32MHz crystal oscillator featuring ±20 ppm frequency stability, tailored for surface mount applications with a 4-pin HCMOS output. This oscillator operates on a 5V supply voltage with a tolerance of 10%, offering stable performance over a temperature range from -40°C to +85°C, making it suitable for industrial and electronic component manufacturing.
Compact in size with dimensions of 7mm length, 5.2mm width, and 5mm height, the device supports high-density circuit designs. The oscillator provides a quick start-up time of 10 milliseconds and includes output enable/disable control with timing of 100 nanoseconds, ensuring precise circuit synchronization.
Constructed with a seam seal method and free from lead (Pb), it complies with RoHS environmental standards. The robust design handles a maximum soldering temperature of 260°C for up to 10 seconds twice, facilitating surface mount assembly processes without damage.
This crystal oscillator is ideal for use in industrial electronics, telecommunications, computing, automotive electronics, and other applications requiring reliable and accurate frequency generation. The tape & reel packaging supports automated manufacturing and efficient component handling.
Operates with 5V supply voltage ±10% for consistent output. Stable frequency of 32MHz with ±20 ppm accuracy. Wide operating temperature range from -40°C to 85°C. Compact 4-pin surface mount package measuring 7x5.2x5 mm. Lead free and RoHS compliant for environmental safety.
Maximum soldering temperature of 260°C and 10 seconds x 2 maximum soldering time. Quick start-up time of 10 milliseconds for fast operation. Tape & reel packaging to support automated PCBA manufacturing. Explore a wide range of Crystal Oscillators and surface mount devices in EnvMart for industrial and electronic component applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Abracon FO7HHAAE32.0-T1 operates at a frequency of 32MHz with a frequency stability of ±20 ppm.
It requires a supply voltage of 5V ±10% for reliable performance.
The functional temperature range is from -40°C to +85°C, making it suitable for diverse environments.
This model has compact dimensions of 7mm in length, 5.2mm in width, and 5mm in height.
It is packaged in tape & reel format, facilitating automated assembly processes.
The oscillator features an HCMOS output level, suitable for various electronic applications.
The maximum soldering temperature is 260°C, with a maximum soldering time of 10 seconds, twice.
Yes, it is lead (Pb) free and complies with RoHS standards for environmental safety.
It has a fast start-up time of 10 milliseconds, ensuring quick operation.
The Abracon FO7HHAAE32.0-T1 features a 4-pin configuration.
This model is ideal for industrial electronics, telecommunications, computing, and automotive applications requiring precise timing.
It is constructed using a seam seal method, ensuring reliability in surface mount applications.
