MEAN WELL Single Output Enclosed Regulated Isolated DC-DC Converter 24V DC Output, 72-144V DC Input, Chassis SD-200D-24

MEAN WELL SD-200D-24 DC/DC Converter is a single output, enclosed, regulated, and isolated unit designed for efficient DC voltage conversion in industrial and electronic applications. It accepts a wide input voltage range from 72V up to 144V DC and provides a regulated 24V DC output with a maximum power of 201.6W. The high isolation voltage of 1.5kV AC reduces noise and enhances electrical safety.

This converter features a rugged chassis mount design for easy installation and integration into control panels and electronic systems. The compact dimensions of 215mm length, 115mm width, and 50mm depth along with a weight of 1.1kg make it suitable for space-constrained setups.

MEAN WELL’s advanced design includes overvoltage, overload, and short circuit protections, making it reliable and durable for continuous operation. With an efficiency rating of 84%, it minimizes energy loss and heat generation, thus contributing to system stability.

The output voltage is adjustable within a 30V range to accommodate varying application requirements. The converter supports an output current up to 10A, ensuring stable power delivery.

Operating temperature spans from -20°C to +60°C, making it versatile for use in demanding industrial, HVAC, manufacturing, laboratory, and electronic power supply contexts. MEAN WELL SD-200D-24 is certified to meet EN, IEC, and UL standards, assuring compliance with international safety and quality benchmarks.

This reliable converter features a wide 2:1 input voltage range for versatile operation. It offers a single output with 10A maximum current and adjustable output voltage range of 30V. Designed with high isolation voltage of 1.5kV AC ensuring safety and noise reduction.

The unit operates efficiently with 84% efficiency and robust protection including short circuit, overload and overvoltage safeguards. Compact chassis mount form factor with dimensions 215mm (L) x 115mm (W) x 50mm (D) and weight of 1.1kg.

Suitable for industrial, laboratory, and electronic equipment requiring stable DC power conversion. Operating temperature range from -20°C to 60°C ensures reliable performance in various environments. Explore the MEAN WELL DC/DC Converter range for high-quality power solutions at EnvMart.
