Panasonic Shielded Wirewound Surface Mount Inductor Metal Composite Core 330 nH ±20% 53.5 A Idc ETQP8M
Specifications
| Country of Origin | India |
|---|---|
| Brand | Panasonic |
| Height | 8mm |
| Length | 12.6mm |
| Model | ETQP8M |
| Depth | 13.2mm |
| Packaging | Tape & Reel |
| Series | ETQP8M |
| Maximum Operating Temperature | 160°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Metal Composite |
| Inductance | 330nH |
| Standards/Approvals | RoHS |
| Package/Case | Surface Mount |
| Maximum DC Current | 53.5A |
| Pin Count | 2 |
| Maximum DC Resistance | 0.77mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 100kHz |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
Key Features
- Designed with a metal composite core for high heat resistance and reliability.
- High vibration resistance due to integral construction.
- Operates up to 160°C including self heat management.
- Features shielded construction for noise reduction.
- Supports automotive standard AEC-Q200 for robust automotive applications.
- Inductance stability provided by ferrous alloy magnetic material.
- Low audible noise suitable for sensitive electronics.
- Ideal for noise filtering in various drive circuitry requiring high temperature and peak current handling.
Product Description
Panasonic ETQP8M Shielded Wirewound Surface Mount Inductor is a high-performance electronic component designed for industrial and automotive applications. Featuring a metal composite core, this wirewound inductor offers exceptional heat resistance, vibration stability, and reliability under demanding conditions.
It delivers an inductance value of 330 nH with a tolerance of ±20%, suitable for precise filtering and energy storage in power circuits. The component supports a maximum DC current of 53.5 A and operates efficiently up to 160°C, making it suitable for high-temperature environments.
The shielded construction minimizes electromagnetic interference, ensuring signal integrity and low audible noise. Its surface mount termination style allows for efficient PCB assembly and compact design integration.
This inductor complies with the automotive standard AEC-Q200, ensuring quality and durability for automotive electronics. The component is molded and designed with ferrous alloy magnetic material, enhancing inductance stability under bias current and temperature variations.
Typical industrial applications include power management, noise filtering in drive circuits, and other use cases requiring high temperature operation and peak current handling capabilities. The compact size (12.6 mm length x 8 mm height x 13.2 mm depth) and tape & reel packaging support efficient manufacturing processes.
Designed with a metal composite core for high heat resistance and reliability. High vibration resistance due to integral construction. Operates up to 160°C including self heat management. Features shielded construction for noise reduction.
Supports automotive standard AEC-Q200 for robust automotive applications. Inductance stability provided by ferrous alloy magnetic material. Low audible noise suitable for sensitive electronics. Ideal for noise filtering in various drive circuitry requiring high temperature and peak current handling.
Surface mount package with tape & reel packaging. Compact size with dimensions 12.6 mm length, 8 mm height, and 13.2 mm depth. Explore the Surface Mount Inductor category for additional high-quality components from Panasonic and other leading brands on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 330 nH with a tolerance of ±20%.
It supports a maximum DC current of 53.5 A.
This inductor operates efficiently up to a maximum temperature of 160°C.
It features a wirewound construction with a metal composite core.
The dimensions are 12.6 mm in length, 8 mm in height, and 13.2 mm in depth.
The termination style is surface mount, which allows for efficient PCB assembly.
It complies with the automotive standard AEC-Q200 and is RoHS certified.
The minimum operating temperature is -40°C.
The maximum self-resonant frequency is 100 kHz.
It is suitable for power management and noise filtering in drive circuits, particularly in high-temperature environments.
It is packaged in tape and reel format for efficient manufacturing processes.
The core is made from ferrous alloy magnetic material, which enhances inductance stability under varying conditions.
