TRACOPOWER Switching Regulator, Through Hole, 3.3V DC Output Voltage, 2 A Output Current TSR 2-2433
Specifications
| Country of Origin | Taiwan |
|---|---|
| Brand | TRACOPOWER |
| Efficiency | 91% |
| Length | 14mm |
| Model | TSR 2-2433 |
| Depth | 10.1mm |
| Gross Weight | 2.6g |
| Width | 7.5mm |
| Mount Type | Through Hole |
| Series | TSR 2 |
| Output Current | 2A |
| Maximum Operating Temperature | 85°C |
| Package Type | SIP |
| Load Regulation | 1 % |
| Minimum Operating Temperature | -40°C |
| MTBF | 13520000h |
| Number of outputs | 1 |
| Ripple and Noise | 50mV Pk-Pk |
| Maximum Input Voltage | 36V dc |
| Line Regulation | 0.5 % |
| Standards/Approvals | IEC/EN 60950-1, UL 94 V-0, UL 60950-1, MIL-STD-810F |
| Minimum Input Voltage | 4.75V |
| Output Voltage 1 | 3.3V dc |
Key Features
- Operates with an efficiency of 91% for minimal power loss.
- Features integral short circuit protection ensuring device safety.
- Supports a wide operating temperature range from -40°C to 85°C.
- Designed as a direct drop-in upgrade for LMxx series linear regulators.
- Low ripple and noise of 50mV peak-to-peak guarantees stable output.
- Compact dimensions with length 14mm, width 7.5mm, and depth 10.1mm.
- Conforms to IEC/EN 60950-1, UL 94 V-0, UL 60950-1, and MIL-STD-810F standards.
Product Description
TRACOPOWER TSR 2-2433 is a high-performance switching regulator designed for efficient DC-DC voltage conversion in electronic components and power supply applications. With a 3.3V DC output voltage and 2 A current capability, this through-hole SIP package regulator provides an ultra-compact solution for power regulation needs.
This switching regulator boasts an efficiency of up to 91%, reducing heat dissipation requirements and improving system reliability. Its robust construction supports a broad operating temperature from -40°C to 85°C, suitable for harsh industrial and commercial environments.
The TSR 2 series is compatible with legacy LMxx linear regulator footprints, offering easy upgrades that provide superior output accuracy and significantly lower standby current consumption. The device incorporates integral short circuit protection to safeguard equipment.
Electrical characteristics include a low ripple and noise of 50mV peak-to-peak, line regulation of 0.5%, and load regulation of 1%. Dimensions are precisely optimized for compact applications, measuring 14mm in length, 7.5mm in width, and 10.1mm in depth with a lightweight of 2.6 grams.
Standards compliance encompasses IEC/EN 60950-1, UL 94 V-0 flammability rating, UL 60950-1, and MIL-STD-810F, ensuring high product safety and reliability for industrial, laboratory, electronic design, HVAC, manufacturing, and power distribution applications.
Operates with an efficiency of 91% for minimal power loss. Features integral short circuit protection ensuring device safety. Supports a wide operating temperature range from -40°C to 85°C. Designed as a direct drop-in upgrade for LMxx series linear regulators.
Low ripple and noise of 50mV peak-to-peak guarantees stable output. Compact dimensions with length 14mm, width 7.5mm, and depth 10.1mm. Conforms to IEC/EN 60950-1, UL 94 V-0, UL 60950-1, and MIL-STD-810F standards. Explore more high-quality Switching Regulators and voltage converters from TRACOPOWER in the Electronics Components category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model provides an output voltage of 3.3V DC and an output current capability of 2A.
The TSR 2-2433 operates with an efficiency of 91%, which helps minimize power loss.
The dimensions of this unit are 14mm in length, 7.5mm in width, and 10.1mm in depth.
It supports a wide operating temperature range from -40°C to 85°C, making it suitable for various environments.
This model is designed for through hole mounting, allowing for easy installation in various applications.
The TSR 2-2433 has a low ripple and noise specification of 50mV peak-to-peak, ensuring stable output.
It conforms to IEC/EN 60950-1, UL 94 V-0, UL 60950-1, and MIL-STD-810F standards, ensuring compliance with safety and reliability requirements.
The load regulation for the TSR 2-2433 is 1%, providing consistent output under varying load conditions.
It features a line regulation of 0.5%, which helps maintain output voltage stability despite input voltage changes.
This switching regulator weighs 2.6 grams, making it lightweight and suitable for compact applications.
The maximum input voltage for the TSR 2-2433 is 36V DC, allowing it to handle a wide range of input conditions.
The minimum input voltage required for this model is 4.75V, ensuring proper operation within specified parameters.
