Bourns 1812 Multilayer Surface Mount Inductor with Ferrite Core 15 μH ±10% 750 mA DC Current CC453232A
Specifications
| Country of Origin | China |
|---|---|
| Brand | Bourns |
| Height | 3.2mm |
| Length | 4.5mm |
| Model | CC453232A |
| Depth | 3.2mm |
| Packaging | Tape & Reel |
| Series | CC453232A |
| Maximum Operating Temperature | 150°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 15μH |
| Standards/Approvals | RoHS |
| Package/Case | 1812 |
| Maximum DC Current | 750mA |
| Maximum DC Resistance | 610mΩ |
| Inductance Tolerance | ±10 % |
| Termination Style | Solder |
| Maximum Self Resonant Frequency | 14MHz |
| Minimum Quality Factor | 20 |
| Inductor Construction | Ferrite Core |
| Automotive Standard | AEC-Q200 |
Key Features
- The inductor supports a maximum DC current of 750 mA.
- Manufactured in China with an automotive standard of AEC-Q200 compliance.
- Package type is 1812 with tape and reel packaging suitable for automated assembly.
- Operating temperature ranges from -40°C to 150°C for versatile applications.
- Maximum DC resistance is 610 mΩ, ensuring low energy loss.
- Maximum self-resonant frequency is 14 MHz, suitable for high-frequency circuits.
- Termination style is solder for reliable surface mounting.
- Constructed with a ferrite core and epoxy resin enclosure for durability and mechanical shock resistance.
Product Description
Bourns CC453232A is a high-quality 1812 multilayer surface mount inductor incorporating a ferrite core designed for efficient inductance performance in compact electronics. This inductor has an inductance of 15 μH with a tolerance of ±10%, allowing precise filtering and energy storage in electronic circuits.
It supports a maximum DC current of 750 mA and operates reliably within a wide temperature range from -40°C to 150°C, meeting automotive industry standards (AEC-Q200). The package case size is 1812 and the product is supplied in tape and reel packaging, facilitating automated PCB assembly.
The ferrite core and epoxy resin enclosure provide robust protection against mechanical shock and pressure, maintaining tight dimension tolerances for automatic placement processes.
With a maximum DC resistance of 610 mΩ and a minimum quality factor of 20, this inductor is efficient and suitable for high-frequency applications up to 14 MHz. Its solder termination style ensures secure mounting on printed circuit boards.
The inductor meets RoHS standards ensuring environmental compliance. Its core material of ferrite contributes to high magnetic performance. Designed specifically for industrial, automotive electronics, and telecommunications equipment.
Package contains one surface mount inductor suitable for assembling advanced electronic devices.
Chosen for reliability and compact design, the Bourns CC453232A multilayer surface mount inductor is ideal for manufacturers needing performance and adherence to industrial standards.
Explore more Surface Mount Inductors and electronic components in EnvMart’s comprehensive catalog to find the perfect part for your application requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 15 μH with a tolerance of ±10%.
It supports a maximum DC current of 750 mA.
The operating temperature range is from -40°C to 150°C.
The maximum self-resonant frequency is 14 MHz, making it suitable for high-frequency applications.
This inductor uses a solder termination style for reliable surface mounting.
The dimensions of this inductor are 4.5 mm in length, 3.2 mm in height, and 3.2 mm in depth.
The maximum DC resistance is 610 mΩ, ensuring low energy loss.
It is constructed with a ferrite core and an epoxy resin enclosure for durability.
Yes, it is compliant with the automotive standard AEC-Q200 and meets RoHS standards for environmental compliance.
This model is packaged in tape and reel format, suitable for automated assembly processes.
The minimum quality factor is 20, indicating its efficiency in performance.
It is designed specifically for industrial, automotive electronics, and telecommunications equipment.
