Wurth Elektronik PCB Header WR-WTB Series Right Angle Through Hole 7 Contact 2.5 mm Pitch Shrouded 68800711722
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 250V |
| Brand | Wurth Elektronik |
| Orientation | Right Angle |
| Current | 3A |
| Mount Type | Through Hole |
| Housing Material | Polyamide |
| Contact Material | Brass |
| Series | WR-WTB |
| Termination Type | Solder |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -25°C |
| Number of Rows | 1 |
| Pitch | 2.5mm |
| Contact Plating | Tin |
| Number of Contacts | 7 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
Key Features
- The housing is constructed from durable polyamide material ensuring resistance to wear.
- Contacts are made of brass and plated with tin for good conductivity and corrosion resistance.
- Rated for 3 A current and 250 V voltage, suitable for various electronic PCB applications.
- Designed for operating temperature range from -25°C to 85°C, accommodating typical industrial environments.
- Connector is RoHS compliant and UL approved, ensuring safety and environmental standards.
- Mounting type is through hole with male contact gender, ideal for wire-to-board connectivity.
- The connector system is wire-to-board with a stamped contact type and UL94 V-0 insulator flammability rating.
Product Description
Wurth Elektronik 68800711722 PCB Header WR-WTB Series is a high-quality electronic connector designed for through hole applications with a right angle orientation. This shrouded, single-row header features 7 brass contacts plated with tin and spaced at 2.5 mm pitch, ensuring reliable electrical connections in PCB assemblies.
Constructed using robust polyamide housing, this component offers excellent mechanical stability and resistance to environmental factors. The connector supports a current rating of 3 A and voltage rating up to 250 V, making it suitable for varied electronic circuits and industrial equipment.
It operates reliably across a temperature range of -25°C to 85°C, suitable for many industrial and commercial uses. The component complies with RoHS directives and holds UL approval, reflecting its adherence to safety and environmental standards.
The termination type is solder, enabling secure and durable mounting through hole on printed circuit boards. Its shrouded design enhances user safety and protection of the contacts, minimizing accidental shorts or damage.
This PCB header serves versatile applications in electronics manufacturing, including control systems, power distribution boards, and signal processing modules in industrial, laboratory, and commercial electronics.
Durable polyamide housing for long service life. 7 male brass contacts plated with tin for corrosion resistance. Rated 3 A current and 250 V voltage for diverse applications. Shrouded, right angle, through hole mounting ensures secure installation.
Operating temperature range from -25°C to 85°C for industrial environments. Compliant with RoHS and UL standards for safety and sustainability. Ideal for wire-to-board connections requiring reliable performance. Discover more from the Wurth Elektronik range and find additional PCB Headers and connectors at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for a current of 3 A and a voltage of 250 V, making it suitable for various electronic applications.
The housing is made from polyamide, while the contacts are brass plated with tin for good conductivity and corrosion resistance.
It operates reliably within a temperature range of -25°C to 85°C, accommodating typical industrial environments.
This unit features 7 contacts, all of which are male and shrouded for added protection.
It is designed for through hole mounting, allowing for secure installation on printed circuit boards.
Yes, it is RoHS compliant and UL approved, ensuring it meets safety and environmental standards.
The contacts are spaced at a pitch of 2.5 mm, which is standard for many electronic applications.
This model uses a solder termination type, which provides a secure connection to the PCB.
It has a right angle orientation, which is beneficial for space-constrained applications.
The connector system is wire-to-board, suitable for various electronic circuit connections.
The country of origin for this product is China.
It is suitable for various applications in electronics manufacturing, including control systems and power distribution boards.
