Samtec TSW Series Straight Through Hole Pin Header 10 Contacts 2.54 mm Pitch 1 Row Unshrouded TSW-109-06-T-S
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 550V |
| Brand | Samtec |
| Orientation | Straight |
| Model | TSW-109-06-T-S |
| Mount Type | Through Hole |
| Special Features | Many options fo |
| Housing Material | Glass Filled Polyester |
| Contact Material | Phosphor Bronze |
| Series | TSW |
| Termination | Through-hole |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 10 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Contact System | .025" (0.635 mm) square post |
Key Features
- The connector features a pitch of 2.54 mm suitable for PCB connections.
- It has 10 male contacts arranged in a single row.
- Constructed with glass filled polyester housing for durability.
- Contacts are made of phosphor bronze with gold plating for reliable conductivity.
- Designed for through-hole mounting on printed circuit boards.
- Operational temperature range from -55°C to 125°C ensures reliable performance.
- Rated for voltage up to 550 V supporting diverse electronic applications.
- Termination type is solder for effective and firm electrical connection.
Product Description
Samtec TSW-109-06-T-S is a precise and durable pin header from the TSW series designed for straight through hole mounting applications. It features 10 male contacts arranged in a single row with a 2.54 mm pitch, making it ideal for board-to-board connections in various electronic assemblies. The housing is made from glass filled polyester, providing excellent mechanical strength and heat resistance, which is further enhanced by an operating temperature range from -55°C up to 125°C.
The contacts are phosphor bronze plated with gold to ensure low contact resistance and corrosion protection, thus guaranteeing reliable electrical performance over time. This unshrouded pin header employs a solder termination method, facilitating strong mounting to printed circuit boards.
Rated for voltages up to 550 V, this connector suits a broad range of industrial and commercial equipment requiring robust, reliable electrical connections. The contact system utilizes a 0.025 inch (0.635 mm) square post format, supporting precise alignment and secure fitment.
This pin header is widely used in sectors including electronics manufacturing, industrial controls, and instrumentation where high contact reliability and mechanical robustness are crucial.
The connector features a pitch of 2.54 mm suitable for PCB connections. It has 10 male contacts arranged in a single row. Constructed with glass filled polyester housing for durability. Contacts are made of phosphor bronze with gold plating for reliable conductivity.
Designed for through-hole mounting on printed circuit boards. Operational temperature range from -55°C to 125°C ensures reliable performance. Rated for voltage up to 550 V supporting diverse electronic applications. Termination type is solder for effective and firm electrical connection.
Contact system uses 0.025 inch (0.635 mm) square post for precision. Suitable for board-to-board connector applications in industrial electronics. Explore more from the Samtec range of PCB components to support your electronic design and manufacturing needs.
Explore more products in our PCB Pin Header category.
