Samtec TSW Series Straight Through Hole Pin Header 15 Contacts 2.54 mm Pitch 3 Row Unshrouded TSW-105-08-T-T-RA
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 550V |
| Brand | Samtec |
| Orientation | Straight |
| Model | TSW-105-08-T-T-RA |
| Mount Type | Through Hole |
| Special Features | Many options fo |
| Housing Material | Glass Filled Polyester |
| Contact Material | Phosphor Bronze |
| Series | TSW |
| Termination | Through-hole |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 3 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 15 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Contact System | .025" (0.635 mm) square post |
Key Features
- Features a glass filled polyester housing for durability.
- Utilizes gold-plated phosphor bronze contacts for reliable conductivity.
- Designed for through-hole mounting on PCBs.
- Supports an operating temperature range from -55°C to 125°C.
- Compatible with board-to-board connector systems.
- Male contact gender with solder termination type ensures secure connections.
- Rated for voltage up to 550 V for industrial and electronic applications.
- Vertical straight orientation with a row pitch of 2.54 mm.
Product Description
The Samtec TSW-105-08-T-T-RA is a high-quality Straight Through Hole Pin Header designed for PCB applications requiring 15 contacts arranged in 3 rows with a 2.54 mm pitch. Manufactured with a robust glass filled polyester housing, it ensures mechanical strength and reliability in demanding environments.
This connector features gold-plated phosphor bronze contacts that provide excellent conductivity and corrosion resistance. The unshrouded design allows for flexible mating configurations, making it suitable for various industrial electronics, instrumentation, and manufacturing assemblies.
Designed for through-hole mounting, the pin header supports a maximum operating temperature of 125°C and a minimum of -55°C, ensuring stable performance across a wide temperature spectrum. It accommodates a voltage rating up to 550 V, catering to moderate voltage usage in electronic circuits.
The connector system is optimized for board-to-board applications with a vertical straight orientation, facilitating straightforward integration in PCB layouts. The solder termination type enhances the mechanical and electrical connection quality during assembly.
Typical use cases include industrial electronics, control systems, communication devices, and other applications requiring reliable multi-contact board interconnection. The 15-position pin header offers flexibility for complex circuit designs and dense component layouts.
Glass filled polyester housing ensures durable mechanical properties. Gold-plated phosphor bronze contacts guarantee high conductivity and corrosion resistance. Through-hole mounting facilitates robust PCB connections. Wide operating temperature range from -55°C to 125°C supports diverse environments.
Voltage rating of 550 V suitable for medium voltage applications. Compatible with board-to-board connector systems for layered circuit designs. Unshrouded 3-row design provides versatile mating options. Male contacts with solder termination for secure assembly.
Explore the full range of PCB Headers on EnvMart for quality connectors and reliable electronic components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pin header is rated for a maximum voltage of 550 V, making it suitable for medium voltage applications in electronic circuits.
It supports an operating temperature range from -55°C to 125°C, ensuring stable performance across various environments.
This model features 15 contacts arranged in 3 rows, with a pitch of 2.54 mm.
The housing is made of glass filled polyester, while the contacts are constructed from gold-plated phosphor bronze for reliable conductivity.
It utilizes a solder termination type, which ensures secure connections during assembly.
Yes, it is specifically designed for through-hole mounting on PCBs, facilitating robust connections.
The contact gender is male, allowing for compatibility with female connectors in board-to-board applications.
The TSW-105-08-T-T-RA has a vertical straight orientation, which simplifies integration into PCB layouts.
It is compatible with board-to-board connector systems, making it suitable for layered circuit designs.
The contacts are gold-plated, which enhances conductivity and provides corrosion resistance.
The pin header is manufactured in India, ensuring quality standards are met during production.
This model offers many options for flexible mating configurations due to its unshrouded design, making it versatile for various applications.
