Samtec TSM Series Vertical Surface Pin Header 6 Contacts 2.54 mm Pitch 2 Row Unshrouded TSM-103-01-T-DV-TR
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 475V |
| Brand | Samtec |
| Orientation | Vertical |
| Current | 5.4A |
| Model | TSM-103-01-T-DV-TR |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | TSM |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 6 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
Key Features
- Constructed with liquid crystal polymer housing for durability and heat resistance.
- Phosphor bronze contact material plated with gold for excellent conductivity and corrosion resistance.
- Designed for surface mount technology with a vertical orientation and board-to-board connector system.
- Operates reliably from -55°C to 125°C, suitable for various industrial environments.
- Rated for a voltage of 475 V AC and a current capacity of 5.4 A.
- Termination type is solder, ensuring secure electrical connection.
- Unshrouded design allows easy access for mating connectors and testing.
- Ideal for electronic components, power connectors, and PCB applications.
Product Description
Samtec TSM-103-01-T-DV-TR is a high-quality TSM series vertical surface pin header designed for industrial and electronic applications requiring reliable board-to-board connections. Featuring 6 contacts arranged in a double-row with a 2.54 mm pitch, this header ensures precise alignment and robust mechanical stability.
The housing is made from liquid crystal polymer, providing excellent dimensional stability and performance at elevated temperatures ranging from -55°C to 125°C. Contacts are constructed from phosphor bronze and plated with gold to provide superior electrical conductivity and resistance to corrosion.
This pin header is designed for surface mount technology (SMT) and offers a vertical body orientation that facilitates easy assembly and soldering onto printed circuit boards.
The connector system supports board-to-board interfacing, widely used in electronic devices, power supply modules, and industrial automation equipment. The connector is unshrouded, allowing straightforward access to contacts during assembly or maintenance.
Electrical specifications include a voltage rating of 475 V AC and a current rating of 5.4 A, suitable for moderate power applications. Liquid crystal polymer housing offers heat resistance and durability. Gold-plated phosphor bronze contacts provide excellent conductivity.
Unshrouded double-row configuration with 6 contacts in total. Surface mount with vertical orientation for PCB applications. Voltage rating: 475 V AC and current rating: 5.4 A for reliable power transmission. Operating temperature from -55°C to 125°C, suitable for harsh environments.
Solder termination type ensures secure connections.
This connector is ideal for use in electronics manufacturing, industrial automation, and power distribution systems. It supports reliable and efficient electrical connections critical in high-performance electronic assemblies.
Explore more products within the PCB Headers category at EnvMart for compatible connectors and electronic components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The voltage rating of this pin header is 475 V AC, making it suitable for moderate power applications.
This model has a current capacity of 5.4 A, which is adequate for various electronic applications.
It operates reliably within a temperature range of -55°C to 125°C, suitable for harsh industrial environments.
The housing is constructed from liquid crystal polymer, while the contacts are made of phosphor bronze and plated with gold for enhanced conductivity and corrosion resistance.
This pin header features a total of 6 contacts arranged in a double-row configuration.
The termination type for this model is solder, ensuring a secure electrical connection.
The pitch size of the contacts is 2.54 mm, which ensures precise alignment during assembly.
This pin header has a vertical orientation, designed for surface mount technology applications.
This model is unshrouded, allowing easy access for mating connectors and testing during assembly.
It supports a board-to-board connector system, making it suitable for various electronic devices and power supply modules.
The country of origin for this pin header is India.
This pin header is ideal for use in electronics manufacturing, industrial automation, and power distribution systems.
