Wurth Elektronik WR-MPC3 Series Straight Through Hole PCB Header, 3 Contact(s), 3 mm Pitch, 1 Row, Shrouded MPC3
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | 250V |
| Brand | Wurth Elektronik |
| Orientation | Straight |
| Current | 5A |
| Model | MPC3 |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Copper Alloy |
| Series | WR-MPC3 |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 3mm |
| Contact Plating | Tin |
| Number of Contacts | 3 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 3.18mm |
Key Features
- This PCB header is designed with a shrouded straight orientation to ensure secure connections.
- It has a current rating of 5A suitable for moderate power applications.
- Constructed with a liquid crystal polymer housing to provide high durability and heat resistance.
- The contacts are made from copper alloy and plated with tin for corrosion resistance.
- Tail pin length measures 3.18 mm for stable solder termination.
- Suitable for through-hole mounting on printed circuit boards.
- Operating temperature ranges from -40°C to 105°C for reliable performance in harsh environments.
- Male contact gender designed to mate with compatible female receptacle housings.
Product Description
Wurth Elektronik MPC3 straight through hole PCB header is a high-quality connector designed for reliable wire-to-board applications in electronic assemblies. This single row, shrouded male header features 3 contacts aligned with a 3 mm pitch, optimized for secure mechanical and electrical connections on PCB layouts.
The housing is made from durable liquid crystal polymer offering UL94-V0 fire resistance and stability over a wide temperature range from -40°C to 105°C, making it suitable for industrial, automotive, and consumer electronic applications.
Contacts are fashioned from copper alloy with tin plating providing excellent conductivity and corrosion resistance. The tail pin length of 3.18 mm ensures consistent solder joints on printed circuit boards using through-hole mounting techniques.
This connector supports a current rating of 5A with a voltage rating of up to 250V, meeting the requirements of medium power electronic circuits and control systems. This PCB header is designed with a shrouded straight orientation to ensure secure connections.
It has a current rating of 5A suitable for moderate power applications. Constructed with a liquid crystal polymer housing to provide high durability and heat resistance. The contacts are made from copper alloy and plated with tin for corrosion resistance.
Tail pin length measures 3.18 mm for stable solder termination. Suitable for through-hole mounting on printed circuit boards. Operating temperature ranges from -40°C to 105°C for reliable performance in harsh environments.
Voltage rating up to 250V ensuring compatibility with various electronic circuits. Male contact gender designed to mate with compatible female receptacle housings. Made in Taiwan, Province Of China, ensuring quality manufacturing standards.
This Wurth Elektronik WR-MPC3 series header is ideal for industrial electronics, manufacturing equipment, and electronic product prototyping. The shrouded design prevents misconnections and enhances user safety during assembly.
Explore additional Wurth Elektronik PCB connectors and headers for diverse application needs through EnvMart’s comprehensive electronics components category.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The current rating of this PCB header is 5A, making it suitable for moderate power applications.
This model has a voltage rating of up to 250V, ensuring compatibility with various electronic circuits.
The contacts on this connector are aligned with a pitch of 3 mm.
The housing is made from liquid crystal polymer, while the contacts are constructed from copper alloy and plated with tin for corrosion resistance.
The operating temperature range for this PCB header is from -40°C to 105°C.
The tail pin length measures 3.18 mm, ensuring stable solder termination.
Yes, this model is designed for through-hole mounting on printed circuit boards.
The contact gender of this connector is male, designed to mate with compatible female receptacle housings.
This PCB header features 3 contacts in a single row configuration.
The shrouded design of this connector is intended to prevent misconnections and enhance user safety during assembly.
This model is suitable for industrial, automotive, and consumer electronic applications due to its reliable wire-to-board connections.
This PCB header is manufactured in Taiwan, Province Of China, ensuring quality manufacturing standards.
