TRACOPOWER High Efficiency 100W Isolated Metal Case DC/DC Converter 160V Input 2.1A Output 38.4V TEQ 100-7218WIR

TRACOPOWER TEQ 100-7218WIR DC/DC Converter is a high-performance, isolated, single output power supply unit, delivering 100 watts of output power with an output voltage of 38.4V. Its ultra-wide 4:1 input voltage range from 43V minimum to 160V maximum makes it suitable for a variety of demanding industrial environments requiring stable power conversion.

The converter is housed in a rugged, sealed metal case that supports excellent thermal convection cooling and offers high resistance to shock and vibration. It operates reliably across an extended temperature range from -40°C to 95°C, with the capability to function at 85°C without derating, making it suitable for harsh operating conditions.

This DC/DC converter features five individual isolated outputs, each capable of supplying output currents up to 2.1 A. The design incorporates output voltage adjustment range from -20% to +10%, remote ON/OFF control, and an under voltage lockout circuit, enhancing its versatility for various control systems. Isolation between input and output is rated at 2250 VDC, ensuring safety and noise reduction in critical industrial applications.

Its high efficiency up to 90% reduces energy losses and heat generation, which is vital for compact industrial installations. The device complies with stringent industry standards including UL 60950-1, IEC/EN 60950-1, UL 508, and EN50155, and is approved for railway applications.

Ideal applications include battery-operated systems, rail transport electronics, and industrial environments where PCB mounting is not feasible. The unit is designed for chassis mounting, providing ease of installation and robust physical protection.

The converter measures 88.9mm in length and 103.2mm in depth, enabling integration into constrained spaces. Manufactured in Taiwan Province of China, this product ensures quality and compliance with international standards.

Features ultra-wide 4:1 input voltage range for versatile performance. Equipped with 5 isolated outputs providing an output current of 2.1A. Operates efficiently up to 90% ensuring low power loss. Designed for operation in extreme temperatures from -40°C to 95°C.

Constructed with a rugged sealed metal case for excellent thermal convection. Includes output voltage trimming and remote ON/OFF functionality. Offers 2250 VDC isolation voltage enhancing electrical safety. Incorporates under voltage lockout and input protection filter for reliable operation.

Ideal for railway systems, battery-operated devices, and industrial chassis mounting. Compact design with dimensions 88.9mm length and 103.2mm depth.
