STMicroelectronics Dual Operational Amplifier 8 MHz Gain Bandwidth, 2 Channels, 8-Pin SOIC, 2.3V-5.5V TSV912IDT
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 1.25mm |
| Length | 5mm |
| Model | TSV912IDT |
| Width | 4mm |
| Mount Type | Surface |
| Series | TSV91x |
| Output Current | 35mA |
| Maximum Operating Temperature | 125°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 2 |
| Standards/Approvals | RoHS, ECOPACK |
| Pin Count | 8 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 5.5V |
| Minimum Supply Voltage | 2.3V |
| GBP - Gain Bandwidth Product | 8MHz |
| Input Bias Current | 1 pA |
| Vos - Input Offset Voltage | 1.5 mV |
| Slew Rate | 4.5V/μs |
| Low input offset voltage | 1.5 mV max. (A grade) |
| ESD high tolerance | 5 kV |
Key Features
- The operational amplifier is designed for low voltage operation from 2.3 V to 5.5 V.
- It features a low input bias current of 1 pA typical, enhancing precision in sensitive circuits.
- Maximum operating temperature range spans from -40°C to 125°C for robust industrial performance.
- The device provides a high output current capability of 35 mA and a slew rate of 4.5 V/μs for fast signal response.
- It boasts an input offset voltage of 1.5 mV max (A grade) for high accuracy applications.
- The package dimensions include a length of 5 mm, width of 4 mm, and height of 1.25 mm.
- This dual-channel unit is compliant with RoHS and ECOPACK environmental standards.
- The TSV91x series is AEC-Q100 automotive standard qualified, suitable for automotive and industrial use.
Product Description
STMicroelectronics TSV912IDT is a dual operational amplifier featuring an 8 MHz gain bandwidth product, optimized for low power consumption and high-speed applications. Housed in a compact 8-pin SOIC surface-mount package, it supports supply voltages ranging from 2.3 V up to 5.5 V, making it suitable for battery-powered and low voltage systems.
The amplifier delivers a low input bias current of typically 1 pA and a minimal input offset voltage capped at 1.5 mV for A grade devices, ensuring precision in signal amplification tasks. Its slew rate of 4.5 V/μs and output current capability up to 35 mA make it efficient for driving moderate loads with fast transient response.
This device operates reliably across a broad temperature range from -40°C to 125°C, complying with automotive AEC-Q100 standards, highlighting its suitability for automotive electronics as well as industrial control and instrumentation applications.
The TSV91x series, including the TSV912IDT, incorporates robust features such as 5 kV ESD protection and meets RoHS and ECOPACK directives, ensuring environmental compatibility. Low power consumption with typical current of 820 μA.
Unity gain stability for eased circuit design. Rail-to-rail input/output allows maximum dynamic range on low voltage supplies. Dual-channel configuration supports compact multi-channel designs. Compact SOIC package enables efficient PCB layout.
Automotive grade certification with AEC-Q100 compliance. Enhanced ESD tolerance safeguards device longevity.
This operational amplifier is ideal for diverse industrial, automotive, and electronic instrumentation applications where precision and reliability are paramount. It is well suited for sensor interface circuits, portable instrumentation, and general-purpose amplification requiring low noise and high bandwidth characteristics.
Explore the STMicroelectronics TSV912IDT and related Operational Amplifiers in the Amplifiers category at EnvMart for advanced electronic component solutions tailored to industrial and commercial needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of this operational amplifier is 8 MHz.
It operates with supply voltages ranging from 2.3 V to 5.5 V.
The maximum output current capability of this unit is 35 mA.
The input offset voltage for A grade devices is capped at 1.5 mV.
It operates reliably across a temperature range from -40°C to 125°C.
The slew rate of this operational amplifier is 4.5 V/μs.
The package dimensions are 5 mm in length, 4 mm in width, and 1.25 mm in height.
This operational amplifier uses surface mounting.
It complies with RoHS and ECOPACK environmental standards, and is AEC-Q100 automotive standard qualified.
The input bias current is typically 1 pA.
This model features 2 channels.
The operational amplifier has an ESD protection level of 5 kV.
