STMicroelectronics Operational Amplifier, 100 kHz Gain Bandwidth, 14-Pin SOIC, 16V TS27L4IDT
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 1.65mm |
| Length | 8.75mm |
| Model | TS27L4IDT |
| Width | 4mm |
| Mount Type | Surface |
| Series | TS27L4 |
| Output Current | 45mA |
| Maximum Operating Temperature | 125°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 4 |
| Power Supply Voltage | 3 V to 16 V |
| Standards/Approvals | RoHS |
| Pin Count | 14 |
| Maximum Supply Voltage | 16V |
| Minimum Supply Voltage | 3V |
| GBP - Gain Bandwidth Product | 100kHz |
| Input Bias Current | 300 pA |
| Vos - Input Offset Voltage | 12 mV |
| Slew Rate | 0.04V/μs |
| Input Offset Current | 200 pA |
Key Features
- The amplifier operates with a low power consumption of 10 μA per amplifier.
- Supply voltage ranges from 3 V to 16 V, suitable for various industrial applications.
- Slew rate is 0.04 V/μs ensuring stable signal amplification.
- The device features an input offset voltage of 12 mV and an input bias current of 300 pA.
- It has an output current capacity of 45 mA allowing effective driving of loads.
- Operating temperature range is from -40°C to 125°C for robust use in harsh environments.
- Surface mount package type SOIC ensures space-saving PCB layout.
- RoHS compliant for environmental safety.
Product Description
STMicroelectronics TS27L4IDT is a quad operational amplifier designed with excellent consumption-to-speed ratio, optimized for industrial and electronic component applications.
This device is packaged in a 14-pin SOIC surface mount package with dimensions of 8.75 mm length, 4 mm width, and 1.65 mm height, facilitating compact and efficient PCB designs within constrained spaces.
Featuring a gain bandwidth product of 100 kHz and a low slew rate of 0.04 V/μs, the TS27L4IDT ensures precision amplification coupled with low power consumption of just 10 μA per amplifier, making it ideal for battery-powered and low-energy circuits.
The supply voltage ranges broadly from 3 V to 16 V, enabling versatile deployment across multiple electronic designs. Its input offset voltage of 12 mV and input bias current of 300 pA provide excellent signal integrity and minimal distortion.
Designed to operate reliably across a wide temperature span from -40°C up to 125°C, it supports rugged industrial and commercial electronic scenarios, including instrumentation and control systems, power electronics, and data acquisition equipment.
Output current capacity of 45 mA allows it to effectively drive medium loads, while the robust CMOS technology ensures excellent performance with minimal phase margin issues in capacitive load conditions.
The TS27L4IDT is RoHS compliant, ensuring adherence to environmental regulations. This component is essential for applications needing high input impedance, low noise, and reliable operational characteristics in a compact quad amplifier format.
Low power consumption of 10 μA per amplifier for efficient energy use. Wide supply voltage range from 3 V to 16 V for flexible application. Compact 14-pin SOIC surface mount package with small footprint. High gain bandwidth product of 100 kHz suitable for fast signal processing.
Operates over extended temperature range of -40°C to 125°C for industrial environments.
This operational amplifier is a preferred choice for engineers designing analog circuits requiring precise, low-power, and compact amplification solutions. It is widely applied in industrial, commercial electronics, instrumentation, and control systems. Explore more Operational Amplifiers and electronics components at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The TS27L4IDT has a gain bandwidth product of 100 kHz, making it suitable for fast signal processing applications.
This model operates reliably over a temperature range from -40°C to 125°C, suitable for harsh industrial environments.
It has an output current capacity of 45 mA, allowing it to effectively drive medium loads in various applications.
The operational amplifier supports a supply voltage range from 3 V to 16 V, providing flexibility for different electronic designs.
The TS27L4IDT is packaged in a 14-pin SOIC with dimensions of 8.75 mm in length, 4 mm in width, and 1.65 mm in height.
This operational amplifier features an input offset voltage of 12 mV, which helps maintain signal integrity.
The input bias current is 300 pA, contributing to its low noise performance.
The slew rate of this model is 0.04 V/μs, ensuring stable signal amplification.
Yes, the TS27L4IDT is RoHS compliant, adhering to environmental safety regulations.
This operational amplifier uses a surface mount type, specifically designed for efficient PCB layouts.
The TS27L4IDT is a quad operational amplifier, containing four channels for amplification tasks.
The minimum supply voltage is 3 V and the maximum is 16 V, allowing for a broad range of applications.
