TRACOPOWER Isolated DC/DC Converter 15V DC Output 200mA 3W DIP-24 Package TEM 3-2413N
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | Converters / DC-DC Converters TRACOPOWER TEM 3N DC/DC Converter, 15V dc/ 200 mA |
| Brand | TRACOPOWER |
| Efficiency | 80% |
| Length | 32mm |
| Model | TEM 3-2413N |
| Depth | 10mm |
| Mount Type | PCB |
| Series | TEM 3N |
| Maximum Operating Temperature | 80°C |
| Package Type | DIP-24 |
| Minimum Operating Temperature | -40°C |
| MTBF | 700000h |
| Number of outputs | 1 |
| Maximum Output Power | 3W |
| Maximum Input Voltage | 26.4V dc |
| Minimum Input Voltage | 21.6V |
| Number of Pins | 24 |
| Output Voltage 1 | 15V dc |
| Output Current 1 | 200mA |
| Isolation Voltage | 1.5kV dc |
Key Features
- Offers tight output regulation with ±0.5% voltage adjustment range.
- Supports input voltage range of 21.6V to 26.4V DC.
- Provides galvanic isolation with 1.5kV DC isolation voltage.
- Ensures low output ripple and noise of 30 mV peak-to-peak.
- Features short circuit protection for enhanced reliability.
- Designed for industrial and consumer electronics applications.
- Wide operating temperature from -40°C to 80°C maximum.
- Package type is DIP-24 with 24 pins and 32mm length, 10mm depth.
Product Description
TRACOPOWER TEM 3-2413N is an isolated DC/DC converter designed to deliver a stable 15V DC output at 200mA current, with a maximum output power of 3 watts. Enclosed in a DIP-24 package, this converter features a length of 32mm and a depth of 10mm, suitable for PCB mounting applications.
The device operates over an input voltage range of 21.6V to 26.4V DC, providing a fully regulated output voltage with a narrow adjustment tolerance of ±0.5%. The TEM 3N series emphasizes tight output regulation combined with very low ripple and noise levels of just 30 mV peak-to-peak, ensuring clean power delivery for sensitive electronic circuits.
With galvanic isolation rated at 1.5 kV DC, the converter protects against ground loops and interference, making it ideal for industrial and consumer electronics use cases. The unit incorporates short circuit protection and an input filter compliant with EN 55022 Class A, highlighting its reliability and electromagnetic compatibility.
Its operating temperature range is from -40°C up to a maximum of 80°C, supporting harsh environmental conditions. The unit's efficiency of 80% minimizes heat generation and improves energy use.
The TEM 3-2413N has an expected mean time between failures (MTBF) of 700,000 hours, indicating robust durability for long-term operation. It meets EN 60950-1 and UL 60950-1 standards, ensuring compliance with international safety and quality requirements.
Offers tight output regulation with ±0.5% voltage adjustment range. Supports input voltage range of 21.6V to 26.4V DC. Provides galvanic isolation with 1.5kV DC isolation voltage. Ensures low output ripple and noise of 30 mV peak-to-peak.
Features short circuit protection for enhanced reliability. Designed for industrial and consumer electronics applications. Wide operating temperature from -40°C to 80°C maximum. Package type is DIP-24 with 24 pins and 32mm length, 10mm depth.
Efficiency rated at 80% with MTBF of 700000 hours. Complies with EN 60950-1 and UL 60950-1 safety standards.
This converter is widely used in industrial tools, laboratory equipment, control systems, and manufacturing electronics where stable and isolated DC power is essential. Its PCB mounting form factor facilitates easy integration into custom electronic assemblies.
Explore more DC/DC Converters and power supply solutions on EnvMart for your electrical and electronics projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model provides a stable output voltage of 15V DC with a maximum output current of 200mA.
The converter supports an input voltage range of 21.6V to 26.4V DC.
It features a galvanic isolation voltage of 1.5kV DC, protecting against ground loops and interference.
The efficiency of this converter is rated at 80%, which helps minimize heat generation.
The DIP-24 package has a length of 32mm and a depth of 10mm.
It operates within a temperature range of -40°C to 80°C, suitable for harsh environments.
Yes, it includes short circuit protection for enhanced reliability during operation.
It complies with EN 60950-1 and UL 60950-1 safety standards.
The maximum output power of this model is 3 watts.
This unit features a single output.
The expected MTBF for this converter is 700,000 hours, indicating robust durability for long-term operation.
This model is designed for PCB mounting, facilitating easy integration into electronic assemblies.
